Toner Cable SMP260T Transcoder - Manual (Page 2)

Specifications Subject To Change Without Notice Rev 02-13 ©Toner Cable Equipment, Inc.
969 Horsham Road l Horsham, Pennsylvania 19044 USA l Phone: 215-675-2053 Fax: 215-675-7543 l [email protected]
SMP260
Transcoder
DVB-S/S2 Input
Video Transcoding
MPEG-2 MP@ML; MPEG-2 MP@HL
(CBR & VBR) MPEG-4 AVC at MP@L3;
MPEG-4 AVC at HP@L4
Aspect Ratio 4: 3 or 16: 9
SD Resolution PAL (720x576) and NTSC(720x480);
HD Resolution 1080i(1920x1080); 720p(1280x720);
Conversion aspect ratio; resolution, format,
adding subtitle
Audio Audio passthrough/transcoding
VBI/Subtitle PID passthrough
Video Input Bit-rate MPEG-2 SD: 2 Mbps ~ 15Mbps
MPEG-2 HD: 1 0Mbps ~ 20 Mbps
H.264 SD: 1 Mbps ~ 15 Mbps
H.264 HD: 6 Mbps~20 Mbps
Re-multiplexing
PID
Re-mapping and Filtering
MPTS Output Synchronization
Routing Any Input to Any Output
IP & ASI Interface
IP
Interface
1 x 1000 Mbps per port
IP Encapsulation MPEG TS over UDP/RTP
MPEG TS MPTS and SPTS
I/O Processing Up to 12 Streams,
max at 72 Mbps per Streams
Addressing Unicast and Multicast
Management IGMPv2, IGMPv3
Forward Error Correction ProMPEG
ASI
Interface
4 BNC connectors (2 ASI inputs and
2 ASI outputs), 75Ω
MPEG Format 188/204 Bytes
I/O Processing 1 MPTS/SPTS per port,
up to 120 Mbps per port
Management
Interface
100Base-TX, RJ45
NMS Wellav Digital Service Manager
Support SNMP
Physical & Environment
Input Voltage
90 – 260 VAC
Power Consumption Approx 100 W
Rack Space 1 RU
Dimension (WxHxD) 19 x 1.75 x 17.3”
480 x 44 x 440mm
Operating Temperature 0 to 50°C
Storage Temperature -40 to 65°C
Relative Operating Humidity <95%
Order Information
SENTC2
H.264/MPEG-2 to MPEG-2 Transcoder
(12 programs)
SENTC4 MPEG2/H.264 to H.264 AVC Transcoder
(12 programs)
Model Information
Model Number
SMP260-SENTC2 SMP260-SENTC4
Inputs
MPEG-2 SD
√ √
MPEG-2 HD √(6 programs) √(6 programs)
H.264-SD √ √
H.264 - HD √(6 programs) √(6 programs)
Outputs
MPEG-2 SD
√ X
MPEG-2 HD X X
H.264-SD X √
H.264 - HD X √(6 programs)
