Specifications Subject To Change Without Notice

Rev 02-11

©Toner Cable Equipment, Inc.

969 Horsham Road

l

Horsham, Pennsylvania 19044 USA

l

Phone: 215-675-2053 Fax: 215-675-7543

l

[email protected]

Video Inputs:

VGA (with pass-through to monitor)
HDMI (unencrypted)
Component (Y-Cr-Cb)
Composite via Y input for 480i

Input Resolutions:

480i, 480p, 720p, 1080i video

Audio Inputs:

L-R baseband audio, dual RCA
S/PDIF optical audio, 32kHz-192kHz sample rate PCM
HDMI embedded audio, 32kHz-192kHz sample rate PCM

Video Encoding:

MPEG2
Resolutions of 720x480, 1280x720, 1920x1080 - determined by input.
Color Sampling: 4:2:2, 4:2:0
Aspect Ratio: Determined by input.
GOP: size typically 15 frames incl. I, P, and B frames.

Audio Encoding:

MPEG1, Layer 2 (MP2)

QAM Output:

64QAM or 256QAM, ITU Annex B
5 - 1000MHz frequency coverage
STD, HRC, IRC, and Broadcast channel plans
+45dBmV output power
15dB output level adjustment range
Phase noise = -95dBc @ 10KHz offset
Broadband noise = -75dBc @ > +/-12MHz offset
MER = >40dB equalized
Channel frequency response = < 1dB
Carrier suppression > 40dB
I/Q inbalance < 1degree
Output level accuracy = +/-1dB

Format:

Table-top chassis, with optional 2-unit mounting in 1RU 19" rack

Control:

Front-panel buttons and LCD for local control
On-board ethernet connection for remote control

Power:

+5V @ 1.7A

**

Preliminary Specifications, Subject to Change**

Specifications

DSE24

High Definition Digital Signage Encoder
