Toner Cable NET-EC Network-Managed Video System Controller User Manual
Page 2
©Toner Cable Equipment, Inc.
Specifications Subject To Change Without Notice.
Telephone:
Nationwide:
Fax:
E-mail:
Internet:
NET
-EC Netw
or
k-Mana
ged V
ideo Sytem Contr
oller
215-675-2053
800-523-5947
215-675-7543
http://www.tonercable.com
Programmable Event Controller
Multi-Event Programmable Database
Stand-Alone Operation
Internal High-Accuracy Clock
Non-volatile, Battery-Backed Event and System
Data
Comprehensive System Diagnostics
System Log
Front Panel Configuration and Control
Set Network IP Address, Subnet, Gateway
Force Immediate Event
Function
Activate/Deactivate Schedule
Local and Remote PC Access
Local and Remote Access via TCP/IP Network
Integrated 10/100 Ethernet Port
WinNET Network Management Software Included
Off-Line Event Scheduling
• Media Resource Library
• Drag and Drop Event Scheduling
• Error/Conflict Reporting for Resources and
Channels
On-Line System Monitoring/Updating
• Send and Activate Event Schedules
• Retrieve System Logs
System Control Panel
• Immediate DVD Player/VCR Control
• Switcher Control and Status
PRO-BUS Machine Control
Control for 16 DVD Players and/or VCRs
Four-Function Control (PLAY, STOP, REWIND,
and RECORD)
Individual or Combined Addressing for Group
Control
Interface Types
• Infrared (Adhesive Ring)
• Wired (Mini-Plug and RCA-Plug)
• Parallel (Multi-Pin)
• Serial (RS-422)
Two DVply Digital Video Player Control Parts
Control for Tascam DV-D6500 Single Disc
Commercial/Professional DVD Players
Full Function Control with Random Disc Access
(TITLE:CHAPTER)
Direct RS-232 Connection, External Interface not
Required
Control for External Switchers
Controls External Video/Audio Routing Matrices
from Select Manufacturers
Support 32x32 Input/Output Matrix up to Eight
Levels
All-Level Switching-Audio/Data Levels Follow
Video
User Defined Input/Output Aliases
Five-Year Warranty
SPECIFICATIONS
Power -- 12VDC regulated input with locking coaxial power connector, external AC power adapter accepts
100 to 240VAC 50-60Hz, AC power consumptions 6 watts @ 120VAC
Network -- Eight-position/eight-conductor RJ-45 modular jack, 10/100 BASE-T Ethernet, TCP/IP,
user-configurable IP address, subnet, gateway
Serial -- COM1 DB9M RS-232 switcher control port, two DVply DB9M RS-232 device control ports
PRO-BUS -- One six-position/six-conductor modular jack, LEIGHTRONIX proprietary interface control bus
Internal Clock -- Battery-backed time and date, crystal oscillator for high accuracy, less than .2
seconds/day maximum drift
Dimensions -- One standard 19” rack unit with overall dimensions 1.75”H x 19.00”W x 7.50”D
Weight -- 3 lbs
Certifications -- UL 1419 2nd Ed., CSA22.2 NO. 1-98, FCC Part 15 Class A
FEATURES
