Toner Cable CMN-LA Loudness Analyzer User Manual

Page 3

969 Horsham Road

Horsham, Pennsylvania 19044 USA

Phone: 215-675-2053 Fax: 215-675-7543

[email protected]

Specifications Subject To Change Without Notice

Rev 1

2-12

3G-sDI Input

Input Type . . . . . . . . . . . . . . . . . . 2 active looping inputs
Input Connector Type . . . . . . . . . . BNC, female
Input Impedance . . . . . . . . . . . . . 75 ohms nominal
Signal Source Amplitude . . . . . . . . 800 mV nominal
Signal Source DC Offset . . . . . . . . ±0.5 V
Input Return Loss . . . . . . . . . . . . . ≤-10 dB, 1.485 to 2.97 GHz
Cable EQ . . . . . . . . . . . . . . . . . . . ≥262 ft (80 m) Belden 1694A

HD-sDI Input

Input Type . . . . . . . . . . . . . . . . . . 2 active looping inputs
Input Connector Type . . . . . . . . . . BNC, female
Input Impedance . . . . . . . . . . . . . 75 ohms nominal
Signal Source Amplitude . . . . . . . . 800 mV nominal
Signal Source DC Offset . . . . . . . . ±0.5 V
Input Return Loss . . . . . . . . . . . . . ≤-15 dB, 270 MHz to 1.485 GHz
Cable EQ . . . . . . . . . . . . . . . . . . . ≥100 m, Belden 8281

sD-sDI Input

Input Type . . . . . . . . . . . . . . . . . . 2 active looping inputs
Input Connector Type . . . . . . . . . . BNC, female
Input Impedance . . . . . . . . . . . . . 75 ohms nominal
Signal Source Amplitude . . . . . . . . 800 mV nominal
Signal Source DC Offset . . . . . . . . ±0.5 V
Input Return Loss . . . . . . . . . . . . . ≤-25 dB, 5 to 270 MHz
Cable EQ . . . . . . . . . . . . . . . . . . . ≥300 m, Belden 8281

3G/HD/sD-sDI Output

Output Impedance . . . . . . . . . . . . 75 ohms
Output Return Loss . . . . . . . . . . . ≤-15 dB, 5 MHz to 1.485 GHz
Output Return Loss . . . . . . . . . . . ≤-10 dB, 1.485 to 3 GHz
Output Signal Level . . . . . . . . . . . 800 mV ±10%
Output DC Offset . . . . . . . . . . . . . 0 V ±0.5 V

DVI Output

Output Connector . . . . . . . . . . . . . DVI-I connector supporting DVI-D
Output Resolution . . . . . . . . . . . . 1024×768 (XGA)
Digital Levels . . . . . . . . . . . . . . . . Per DDWG DVI rev 1
Pixel Rate . . . . . . . . . . . . . . . . . . 65 Mp/s

Analog Monitoring Output (Headphone)

Number/Connector . . . . . . . . . . . . 1 stereo output, 1/8-in. (3.5mm) headphone jack
Load Impedance . . . . . . . . . . . . . 16 ohms nominal
Maximum Output Level. . . . . . . . . 44 mW RMS
Total Harmonic Distortion and . . . . ≤–65 dB
Noise (THD+N)

Control (optional)

GPI . . . . . . . . . . . . . . . . . . . . . . . 4 total with 2 input and 2 preset recall selections

or individually user configured as alarm input

GPO . . . . . . . . . . . . . . . . . . . . . . 1 alarm, user-configured
Connector . . . . . . . . . . . . . . . . . . 15-pin HD (high-density) D-sub, female
Input Impedance . . . . . . . . . . . . . 10 k ohms returned to +3.3 VDC
Alarm Output . . . . . . . . . . . . . . . . Relay closure
Maximum Relay Current . . . . . . . . 100 mA @ 50 VDC
Peripheral Interface . . . . . . . . . . . USB 2.0 supporting storage devices
Connector . . . . . . . . . . . . . . . . . . USB 2.0, type A, female

Timecode

Input . . . . . . . . . . . . . . . . . . . . . . (Optional) LTC via back-panel connector

Ancillary timecode (HD only)

DVITC extracted from SD inputs

Communication Interfaces

Ethernet . . . . . . . . . . . . . . . . . . . 1 Ethernet port, RJ-45 connector, 10/100Base-T
USB . . . . . . . . . . . . . . . . . . . . . . 1 USB 2.0 host port
LTC/GPIO . . . . . . . . . . . . . . . . . . . 1 LTC/GPIO connector 15-pin female D-sub

(optional)

ethernet

Standard . . . . . . . . . . . . . . . . . . . 10/100Base-T conforms to IEEE802.3
Connector . . . . . . . . . . . . . . . . . . RJ-45
Performance Metric . . . . . . . . . . . Transfer a captured frame to a PC in 30 sec,

dedicated LAN

Power requirements

Power Connector . . . . . . . . . . . . . 15 VDC nominal

11 VDC minimum, 17 VDC maximum

Power Consumption . . . . . . . . . . . 25 W nominal
Over-Voltage Protection . . . . . . . . ±50 VDC nominal

Mechanical

Dimensions (H x W x D) . . . . . . . . 5.22 x 8.46 x 5.8 in. (13.26 x 21.49 x 14.73 cm)
Weight . . . . . . . . . . . . . . . . . . . . 5 lbs (2.27 kg)

environmental

Operating Temperature . . . . . . . . . 32° to 122° F (0° to 50° C)
Storage Temperature . . . . . . . . . . -22° to 149° F (-30° to 65° C)
Humidity (non-condensing) . . . . . . Operating: 20% to 80%

Non-operating: 5% to 90%

Transportation . . . . . . . . . . . . . . . 24 in. (9.5 cm) impact-drop survivable in original

factory packaging

Altitude . . . . . . . . . . . . . . . . . . . 6562 ft (2000 m)
Pollution Degree . . . . . . . . . . . . . 2

standard Accessories

. . . . . Installation and operation handbook on CD

Breakout connector for LTC/GPI

1 power cord

1 power supply assembly
