MUX-2D-QAM
8VSB/QAM Multiplexer 2x 8VSB/QAM ► QAM
Specifications
Connectors
8VSB/QAM Module:
1 x “F” Female
Emergency Alert System (EAS):
1 x BNC Female
Standards
8VSB:
ATSC Digital Television AV/53E
QAM:
ITU-T J.83 - Annex A & B (64 and 256 QAM)
ASI (EAS Input):
1x DVB-ASI; EN 50083-9
SD single program broadcast MPEG2 or 4 video
and AC-3 Dolby® Audio
8VSB Mode
Tuning Range:
UHF (NTSC Ch. 14-69), VHF (NTSC Ch. 2-13)
Data Rate:
19.392 Mbps
Bandwidth:
6 MHz
Power Level:
-20 to +20 dBmV
QAM Mode
Tuning Range:
CATV (NTSC Ch. 2-135)
Data Rate:
38.8 Mbps (QAM 256); 26.97 Mbps (QAM 64) –
Auto Detect
Bandwidth:
6 MHz
Power Level:
-15 to 20 dBmV (@ QAM 256)
-20 to 20 dBmV (@ QAM 64)
Impedance:
75 Ω
Connector:
1x “F” Female
QAM Modulation Modes:
16, 32, 64, 128, 256, 512, and 1024
DVB Symbol Rate:
Variable; 1 to 7 MSymbols/sec (MBaud)
Frequency Range:
54 to 864 MHz
QAM Tuning:
Per channel’s number from 2 to 135
RF Level:
+45 dBmV
RF Level LCD Screen Error:
± 2 dB
RF Level Adjustment Range:
35 to 45 dBmV
Frequency Stability:
± 10 kHz over 32 to 122 °F (0 to 50 °C)
Frequency Tolerance:
± 0.5 kHz @ 77 °F (25 °C)
Amplitude Flatness:
± 0.25 dB (over 6 MHz channel)
Phase Noise:
-98 dBc (@ 10 kHz)
Spurious:
-60 dBc
Broadband Noise:
-75 dBc (@ +60 dBmV output level,
4 MHz bandwidth)
Impedance:
75 Ω
Return Loss:
12 dB
Spectral Inversion:
Auto Recognition
Carrier Suppression:
55 dB
SNR:
Greater than 40 dB
MER:
Greater than 40 dB
I/Q Phase Error:
Less than 1 degree
I/Q Amplitude Imbalance:
Less than 1%
Encoding Profile
Video:
MPEG 2 HD; ISO 13818-2; 1080i
MPEG 2 SD; ISO 13818-2; 480i
Audio:
Pass through compress audio
Does Not Support Closed Captioning
EAS Looped Output
Connector:
1x BNC Female
Standard:
ASI
Trigger Mechanism:
5-12 VDC & Dry Contact Closure
Local Monitoring:
Front-panel 16-character, 2-line LCD screen
Local Control:
Front-panel Navigational Key-pad
Remote Monitoring/Control:
Not available
INPUT
OUTPUT
ALARMS / MONITORING / CONTROL
Dimensions (W x D x H) :
19.0 x 14.3 x 1.75 inches (483 x 363 x 44 mm)
Power:
100 to 265 VAC/50 to 60 Hz
(Fuse: 1 amp, 250 VDC, SloBlo)
Power Dissipation:
36 W
Weight:
5.1 lbs (2.31 kg)
Operating Temperature:
32 to 122 °F (0 to 50 °C)
Storage Temperature:
-13 to 158 °F (-25 to 70 °C)
Operating Humidity:
0 to 95% RH @ 35 °C max, non-condensing
Storage Humidity:
0 to 95% RH @ 35 °C max, non-condensing
GENERAL
