Encoder Video Profiles
MPEG 2 SD Profile 1: Adaptive Field Frame (AFF)
ISO13818-2 MP@ML
MPEG 2 SD Profile 2: AFF ISO13818-2 422P@ML
MPEG 2 HD Profile 2: ISO13818-2 MP@HL
(1920 x 1080 or 1280 x 720)
Video Encoding Data Rates
MPEG 2 MP@ML SD / 1 Mbs-15 Mbs -
NTSC & PAL
MPEG 2 422P@ML SD / 1 Mbs-50 Mbs -
NTSC & PAL
MPEG 2 MP@HL / 7 Mbs-59.5 Mbs
High Definition Video Frame Formats
720p24, 720p50, 720p60, 1080i50, 1080i60
High Definition Video Encode Resolutions
Horizontal Resolutions 1280, 1920 (1440)
Vertical Resolutions 720, 1080
Standard Definition Video Frame Formats
480i, 576i, 480p, 567p
Standard Definition Video Encode Resolutions
Horizontal Resolutions
720, 704, 640, 544, 528, 480, 352
Vertical Resolutions
480, 576
Video Processing
Encoder Filters (SD Only)
Temporal & Spatial (Median)
Time Base Corrector (TBC) on SDI inputs for SD
only Chroma filtering and scaling for NTSC/PAL
Encoder Video Input
Standard Definition (SD) Video Inputs (Encoder)
Analog NTSC and PAL Composite (BNC)
SDI (SMPTE 259M) with embedded audio
(SMPTE 272M)
Auto detect SD 270Mbps for SD
D1 Encoding Only - no internal up-conversion.
High Definition (HD) Video Inputs (Encoder)
HD-SDI input video, (SMPTE 292M) with
embedded audio (SMPTE 299M)
Auto detect HD 1.485 Gbs.
* SDI and HD-SDI are the same connector with auto
standard (resolution and frame rate) detection.
Encoder Audio Profiles
Dolby Digital 2.0 (AC3) dual stream encoders
option.
MPEG1 Layer 2 dual stream encoders included
Dolby E, Dolby 5.1 and Dolby Digital 2.0 (AC3)
passthrough
Encoder Audio Input
Analog Audio 1 Stereo Balanced (5-Pin
Removable Screw Terminal)
Analog Audio 2 Stereo (SAP) Balanced (5-Pin
Removable Screw Terminal)
AES3-1 digital audio input uncompressed (PCM) or
compressed bit stream passthrough from external
Dolby 2.0, 5.1 or Dolby E encoders (BNC - 75
Ohm). Includes compressed bit stream output.
AES3-2 digital audio input uncompressed (PCM) or
compressed bit stream passthrough from external
Dolby 2.0, 5.1 or Dolby E encoders (BNC - 75
Ohm). Includes compressed bitstream output.
SDI embedded (4 pairs) with video per SMPTE
272M for SD and SMPTE 299M for HD. One user
selectable group.
User-defined analog and digital level control with
sample rate conversion on all inputs
Transport Outputs
ISO13818-1 MPEG 2 Transport Stream
(188 byte only) (x3 mirrored outputs)
MPEG 2 Transport via GIGE (UDP or RTP)
MPEG 2 Transport to local storage Constant
Capture to storage (local or NAS)
ASI, IP and Constant Capture operate concurrently
Transport User Data
SMPTE 334 VANC data extraction for IEEE
708/608. Concurrent
User defined VANC Line 7-32 data extraction
supported
Teletext: (NABTS) DVS053 Rev 6
Conditional Access BISS 1/E option
Table Compliance
MPEG Program Specific Information (PSI) Table
Compliance: PAT; PMT; DVB Service Information (SI)
Table Compliance (Static); SDT; NIT; TDT/TOT; SCTE
35 Splice Point injection; ATSC A65B (PSIP) Table com-
pliance (Static); MGT (TVCT, STT, RRT, EIT)
- For dynamic DVB-SI use Adtec's DTA-3050 and
DTVGuide web hosted EIT SI Server.
- For dynamic A65B PSIP use Adtec's DTA-3051 and
DTVGuide web service
Pro-02-S Decoder Specifications
Decoder Video Output
- Confidence decode of encode via internal bus,
No ASI loop required
- SD/HDSDI SMPTE 259M (SD) and SMPTE 292M
(HD) User definable resolution from D1 to 1080i
including scaler for Up and
Down conversion
- Composite D1 Video (NTSC/PAL) Not concurrent
with HD
- HDMI 1.3 No HDCP
- DVB-ASI Input
- Decoder Audio Output (Decodes only one pair)
- SDI Embedded audio stereo audio pair SMPTE
272M (SD)
SMPTE 299M (HD) User defined PID
- HDMI
- No analog audio output
Decoder Video Profiles
MPEG 2 SD Profile 1: Adaptive Field Frame (AFF)
ISO13818-2 MP@ML
MPEG 2 SD Profile 2: AFF ISO13818-2 422P@ML
MPEG 2 HD Profile 2: ISO13818-2 MP@HL (1920
x 1080 or 1280 x 720)
Decoder Audio Profiles
Dolby Digital AC-3
MPEG 1 Layer 2
Physical
1 RU chassis (19 x 14 x 1.75)
14 pounds
Power
Start-up:72 Watts
Operational: 60 Watts
User Interface Requirements
Supported Browsers
- IE 7 and higher
- Firefox 3.0.0 and higher
- Safari 3.0.0 and higher
- Opera 9.0 and higher
Options
MEDIAHUB-PRO-02: Offers standard definition MPEG 2
encoding.
MEDIAHUB-PRO-02-S: Studio version of encoder adds
confidence decoder, RS422 control and 160GB hard
drive.
MEDIAHUB-PRO-HD-KEY: Enables gigh definition
MPEG 2 encoding. Software Key. Field Upgradable.
MEDIAHUB-PRO-DOLBY-KEY: Adds dual (two-pairs)
stereo Dolby Digital AC3 encode. Software Key. Field
Upgradable
BISS: BISS 1 and BISS E Encryption
Specifications
mediaHUB-Pro 02
MPEG 2 Standard & High Definition Encoder
