HDE-QAM
HD Encoder QAM 1x HDMI ► 1x QAM
Specifications
Connector: HDMI
Video Standard
480i:
720 x 480
720p:
Main profile I & P Frames, 4:2:0 color components,
1280 x 720
1080i:
Main profile I & P Frames, 4:2:2 color components,
1920 x 1080
Transport Rate:
Variable, user-selectable from 9.7 to 100 Mbps
Video Rate:
Variable, user-selectable
Video Pre-filter:
Variable, user-selectable
GOP Size:
Variable, user-selectable from 1 to 60
Intra DC Precision:
Variable, user-selectable from 8- to 11-bit
Chroma Formats:
4:2:0 and 4:2:2 (ITU-R BT.601)
Colorspace Formats:
YCbCR and RGB
Packet Format:
MPEG-2 188-byte Transport Stream
Audio:
Compressed Dolby® Digital Pass-Thru
Indicators:
Power (Green LED)
Encoder (Blue LED)
Temperature (Red LED)
720p (Green LED)
1080i (Green LED)
Local Monitoring:
Front-panel 16-character, 2-line LCD screen
Local Control:
Front-panel Navigational Key-pad
Remote Monitoring/Control:
GUI-based menu via Web browser
INPUT
OUTPUT
ALARMS / MONITORING / CONTROL
Dimensions (W x D x H):
19.0 x 18.125 x 1.75 inches (483 x 460 x 44 mm)
Power:
Operator Selectable @ 115 VAC/60 Hz or 230
VAC/50 Hz (Fuse: 3.0 amp, 250 VDC, Slo Blo)
Power Dissipation:
129 W
Weight:
13 lbs (5.9 kg)
Operating Temperature:
32 to 122 °F (0 to 50°C)
Storage Temperature:
-13 to 158 °F (-25 to 70°C)
Operating Humidity:
0 to 95% RH @ 35°C max, non-condensation
Storage Humidity:
0 to 95% RH @ 35°C max, non-condensation
Certifications:
UL Listed 60950
GENERAL
Connectors:
Primary:
“F” Female
RF Test Port:
“F” Female
QAM Modulation Modes:
16, 32, 64, 128, 256, 512, & 1024
DVB Symbol Rate:
Variable; 1 to 7 MSymbols/sec (MBaud)
Frequency Range:
5.75 to 864 MHz, and
sub-channel 5.75 to 53.75 MHz
QAM Tuning
NTSC:
Per channel’s number from T7 to T14 & 2 to 135
PAL:
8.5 to 861.0 MHz Per channel’s center-frequency
(12.5 kHz increments)
RF Level:
+60 dBmV (120 dB
μV)
RF Level LCD Screen Error:
±2 dB
RF Level Adjustment Range:
50 to 60 dBmV
Frequency Tolerance:
±0.5 kHz @ 77°F (25°C)
Frequency Stability:
±5 kHz over 32 to 122°F (0 to 50°C)
Amplitude Flatness:
±0.25 dB (over 6 MHz channel)
Phase Noise:
-98 dBc (@ 10 kHz)
Spurious:
-60 dBc
Broadband Noise:
-75 dBc (@ +60 dBmV output level,
4 MHz bandwidth)
Impedance:
75
Ω
Return Loss:
12 dB
Spectral Inversion:
Auto Recognition
Carrier Suppression:
55 dB
SNR:
Greater than 40 dB
MER:
Greater than 40 dB
I/Q Phase Error:
Less than 1 degree
I/Q Amplititued Imbalance:
Less than 1%
Encoding Profile
Video:
MPEG-2 HD; ISO 13818-2; 1080i
MPEG-2 SD; ISO 13818-2; 480i
Audio:
Pass through compress audio
Does Not Support Closed Captioning
