DECODING SPECIFICATIONS
Standards
PAL, NTSC, 720p 50/60, 1080i 50/60, 1080p 25/30
Video outputs HD-SDI output: 0,8 V
PP,
75 Ohm (BNC , embedded audio support)
Breakout cable outputs: Composite, S-Video, Component
Video resolutions Full D1: 720h x 480/576v, Half-D1: 352h x 480/576v, CIF/SIF: 360/384h x 288/240v, QCIF: 176h x 144/120v
720p 50/60, 1080i 50/60, 1080p 25/30
Audio outputs
Unbalanced analog stereo, consumer line level
Audio inputs (Talkback) Analog stereo, consumer line– and MIC-level
Video codecs
MPEG-2 (ISO/IEC 13818-2), Main Profile at Main Level (MP@ML), 4:2:0
High Profile at Main Level (HP@ML), 4:2:0
MPEG-4 AVC/H.264 (ISO/IEC 14496-10), Main Profile at Level 3.1 (MP@L3),
Baseline Profile at Level 3.1 (BP@L3), 4:2.0 , High Profile at Level 4 (HP@L4)
Stream types ISO/IEC 13818-1 Transport Streams
Elementary A/V
Audio codecs
MPEG-1 Audio Layer 1, 2 (ISO/IEC 11172-3 Layer 1, 2)
MPEG-4 AAC LC (ISO/IEC 14496-3)
I/O SPECIFICATIONS
Network
10/100TX Ethernet, RJ45, half/full duplex, auto-sensing
Streaming traffic Unicast and multicast traffic supported, TCP, RTP
IP Protocols HTTP (web browser), TCP/IP control protocol, UDP/TCP streaming, IGMPv2, SNMP, DHCP
Error correction: Pro-MPEG FEC (forward error correction) and TCP
RS-232/422 port RS-232 connection via console (remote control for non IP devices via TCP/IP RS-232/422 command tunnelling)
GPI in 1 INPUT, isolated
GPI out 1 OUTPUT, isolated
USB port (For future use)
MANAGEMENT:
Web browser, SNMP, Telnet and RS-232, software updates via web browse
Fault measurement with log generation, authorization via user password, RTC (Real Time Clock) support
ENVIRONMENTAL
Agency approvals CE, RoHS compliant
Humidity Up to 90%, non-condensing
Temperature -25 to +45°C environment temperature; fanless when operated as -PORTABLE
Blade weight Approx. 130 grams
Blade dimensions (H/W/D) 20mm x 130mm x 190mm, Europe Card (160mm x 100mm, 3HE), Conform to IEC60297-3/-4
Power 5Vdc ±10% / 8W per blade
PORTABLE weight Approx. 700 grams
PORTABLE dimensions (H/W/D) 28mm x 104mm x 192mm
Limited warranty 1 year standard limited warranty. Warranty extensions for up to 5 years available.
ORDER INFORMATION
DEC-300
H.264 HD & MPEG-2 HD decoder blade with HD-SDI-, embedded audio-, analog video/audio output.
DEC-300-PORTABLE H.264 HD & MPEG-2 HD portable decoder device with HD-SDI-, embedded audio-, analog video/audio output.
Including power supply.
300-UPG-FEC
Upgrade option for ENC-/DEC-300-Series for forward error correction
BREAKOUT-CABLE-S-D
YC (miniDIN), Composite (RCA jack), analog audio out (RCA jack), analog audio in (3.5 mm phone jack) connectors
incl. RCA jack to 3.5 mm phone plug adapter. Breakout cable S is included in delivery
BREAKOUT-CABLE-P-3D Composite/YC/YP
B
P
R
(all BNC female), analog audio out/in (RCA jack), GPI in/out (Sub-D 9-pin), RS-232/422 (Sub-
D 9-pin) connectors
FR-610
1RU Rack mount chassis for max. 6 blades
FR-610-DPS 1RU Rack mount chassis for max. 6 blades with redundant power supply
FR-2000-24
4RU Rack mount chassis for up to 21 blades (depends on blade combination) with redundant power supply
COMPLEMENTARY PRODUCTS
ENC-300-DVI H.264 HD/SD encoder blade with DVI/HDMI input. Also available as -PORTABLE encoder device.
ENC-300-HDSDI
H.264 HD/SD encoder blade with SDI, PAL/NTSC, Composite, S-Video, Component or analog VGA input. Also
available as -PORTABLE encoder device.
MC-ROUTE-1RU
1RU appliance for live UDP, TCP, FEC, RTSP and HLS streaming and unicast/multicast bridging
***PLEASE NOTE: Live streaming/multicast streaming requires specially designed and configured networks.
Minimum requirements include: Layer-3 switched ethernet, multicast enabled, IGMPv2/3, network and multicast routing supported.
