IPME-2
IP Encoder-AV 1x AV ► 1x IP
Specifications
Connectors
Video:
1x “F” Female
Audio:
2x RCA Female (Left & Right)
Video Standards:
NTSC and PAL
Indicators
IPME-2:
Power (Green LED) & IP Link (Orange LED)
IPME-SM
Active (Green LED) & IP Link (Green LED)
Local Monitoring/Control:
Front-panel RS 232 interface
Remote Monitoring/Control:
GUI-based menu via Web browser
INPUT
OUTPUT
ALARMS / MONITORING / CONTROL
Dimensions (W x D x H):
IPME-2:
4.125 x 7.5 x 1.25 inches (105 x 191 x 132 mm)
IPME-SM:
4.125 x 7.5 x 1.25 inches (105 x 191 x 132 mm)
IPME-CH:
19.0 x 8.25 x 1.75 inches (483 x 210 x 44 mm)
Power:
100 to 265 VAC; 50 to 60 Hz
(Fuse: 3.15 amp, 250 VDC, LBC)
Power Dissipation:
15 W (fully loaded with 3 modules)
Weight:
IPME-2:
0.8 lbs (0.36 kg)
IPME-SM:
0.8 lbs (0.36 kg)
IPME-CH:
5.125 lbs (2.32 kg); Fully loaded
Operating Temperature:
32 to 122 °F (0 to 50°C)
Storage Temperature:
-13 to 158 °F (-25 to 70°C)
Operating Humidity:
0 to 95% RH @ 35°C max, non-condensation
Storage Humidity:
0 to 95% RH @ 35°C max, non-condensation
GENERAL
Connector:
1x RJ-45
Standards (Auto-sensing):
10BaseT Ethernet
100BaseTX Fast Ethernet
Video Compression:
MPEG-2; RFC-1889 & RFC-2250
Video Bandwidth
User-selectable
Minimum:
30 fps @ 1.5 Mbps; 325x240 resolution
Recommended:
30 fps @ 3.8 Mbps; 720x480 resolution
Maximum:
30 fps @ 7.5 Mbps; 720x480 resolution
Streaming Modes:
Uni-cast and Multi-cast
Transport Stream:
UDP, or RTP over UDP
Quality of Service:
Packet Shaping,
Forward Error Correction (FEC)
