Specifications Specifications
Forward Path Return Path
Technology Power Doubling, GaAs, Hybrid Push Pull, Si-Bipolar
Frequency Range 54-1000 MHz 5-42 MHz
Gain 37 dB 24 dB
Input Gain Control Plug-in, fixed value, 0 to 18 dB variable
0 to 20 dB in 2 dB steps
Second Stage Gain Control 0 to 10 dB variable, mid stage Plug-in, fixed value,
0 to 20 dB in 2 dB steps
Input Slope Control Plug in, fixed value, NA
0 to 20 dB in 1 dB steps
Second Stage Slope Control 0 to 10 dB variable, mid stage NA
Input / Output Return Loss 16 dB 16 dB
Noise Figure 6 dB 6 dB
Channel Loading 79 ch analog, digital at -6 dB 4
down after 550 MHz
Output Level 40/50 dBmV 52 dBmV
Composite Triple Beat (CTB) -63 dBc -64 dBc
Composite Second Order (CSO) -65 dBc -68 dBc
Crossmodulation (XMOD) -62 dBc -65 dBc
Impedance 75 ohm 75 ohm
Hum Modulation -70 dBc -70 dBc
Input / Output Test Port Level -30 ±1 dB
Operating Temperature Range -20°C to +55°C
Input / Output Connectors F type
Surge Withstand (IN / OUT) IEEEC 62.41 Cat. A3 (6kV, 200A)
Power Requirement Wall Power Transformer, Input = 90-240 VAC, 50-60 Hz, 1A
Output =24 ±1 VDC, 1.25A
Size (L x W x H) 7 3/4” x 6 1/3” x 3” (195 mm x 160 mm x 79 mm)
Shipping Weight 6 lbs (1.8 kgs)
Ordering Information - Plug In Accessories
Attenuator Pads TBLE-9518**
870 MHz 0 to 22 dB in 1 dB steps (replace ** with dB value)
Forward Equalizer TBLE-9508**
870 MHz 0 to 22 dB in 1 dB steps (replace ** with dB value)
Specifications Subject To Change Without Notice Rev 06-13 ©Toner Cable Equipment, Inc.
