DESCRIPTION AFL NO.
Miscellaneous
ELCT2-20A Electrodes
S013532
ASW-02 Splicing Workstation S010532
JP-05 Splice Sleeve Cooling Tray S014537
CLAMP-S60A Sheath Clamp S014550
(8mm min cleave for 250μm, 16mm min cleave for 900μm)
CLAMP-S60B Sheath Clamp
S014551
(8mm min cleave for 250μm and 900μm)
CLAMP-S60C Sheath Clamp
S014552
(16mm cleave for 900μm loose tube fiber)
CC-24-60S Transit Case (fits only FSM-60S)
S014559
Specifications Subject To Change Without Notice Rev 09-11 ©Toner Cable Equipment, Inc.
969 Horsham Road l Horsham, Pennsylvania 19044 USA l Phone: 215-675-2053 Fax: 215-675-7543 l [email protected]
FSM-60S
Fusion Splicer
Accessories Recommended for the FSM-60S
DESCRIPTION AFL NO.
Cleavers
CT-30A Cleaver
S014080
Fiber Holders (pairs)
FH-60-250 Fiber Holder
S014548
FH-60-900 Fiber Holder S014549
Batteries and Power Cords
ADC-13 AC Adapter
S014535
BTR-08 Battery (160 splice/heat cycles) S014540
DCC-14 Battery Charge Cord (BTR-08) S014541
DCC-12 Power Cord S013552
(connects ADC-13 to cigarette lighter socket)
DCC-13 Power Cord
S013556
(connects ADC-13 to power source via alligator clips)
Specifications
Parameter Value
Model FSM-60S Fusion Splicer
Applicable Fibers Single-mode (ITU-T G.652), multimode (ITU-T G.651), DS (ITU -T G.653), NZDS (ITU-T G.655)
Cladding Diameter 80μm to150μm
Coating Diameter 100μm to 1,000μm
Fiber Cleave Length 8 to 16mm with 250μm coating diameter, 16mm with 900μm coating diameter
Typical Average Splice Loss 0.02dB with Sm, 0.01dB with mm, 0.04dB with DS, 0.04dB with NZDS
measured by cut-back method relevant to ITU-T and IEC standards
Splicing Time Typical 9 seconds with standard single-mode fiber
Arc Calibration method Automatic, real-time and by using results of previous splice when in AUTO mode, manual arc
calibration function available
Splicing modes 100 preset and user programmable modes
Splice Loss Estimate Based upon dual camera core alignment data
Storage of Splice Result Last 2000 results to be stored in the internal memory
Fiber Display X or Y, or both X and Y simultaneously. Front or rear monitor display options with automated
image orientation
Magnification 300X for single X or Y view, or 187X for X and Y view
Viewing method Dual cameras with 4.1 inch TFT color LCD monitor
Operating Condition 0 to 5,000m above sea level, 0 to 95%RH and -10 to 50°C respectively
Mechanical Proof Test 1.96 to 2.25N
Tube Heater Built-in tube heater with 30 heating modes; auto-start function
Tube Heating Time Typical 30 seconds with FP-03 sleeve, 35 seconds with FP3 (40), 35-55 seconds with Fujikura
micro sleeves
Protection Sleeve Length 60mm, 40mm, micro
Splice/Heat Cycles with Battery Typical 160 cycles with power save functions activated
Power Supply Auto voltage selection from 100 to 240V AC or 10 to 15V DC with ADC-11, 13.2V DC with
BTR-08 battery
Terminals USB 1.1 (USB-B type) for PC communication. mini-DIN (6-pin) for HJS-02/03 and SH-8 tube heater
Wind Protection Maximum wind velocity of 15m/s. (34 mph)
Dimensions 136W x 161D x 143H (mm) / 5.3W x 6.3D x 5.6H (inches)
Weight 2.3 kg (5.1 lbs) with AC adapter ADC-11; 2.7kg (5.9 lbs) with BTR-08 battery
