Specifications Subject To Change Without Notice

Rev 04-12

©Toner Cable Equipment, Inc.

969 Horsham Road

l

Horsham, Pennsylvania 19044 USA

l

Phone: 215-675-2053 Fax: 215-675-7543

l

[email protected]

RMDA Series

Rack-Mount Distribution Amplifier

SPECIFICATIONS

RF SPECIFICATIONS

RMDA 550-30S RMDA 550-30 RMDA 550-30P

RMDA-550-50

RMDA 750-15S RMDA 750-30

RMDA 750-30P

Frequency Range (MHz):

47-550

47-550

47-550

47-550

47-750

47-750

47-750

Channel Loading:

77

77

77

77

110

110

110

Flatness (dB):

±0.75

±0.75

±0.75

±0.75

±1.00

±1.00

±1.00

Hybrid Technology :

Push-Pull

Push-Pull Power Doubling

Push-Pull

Push-Pull

Push-Pull

Power Doubling

Gain (dB):

33

33

33

50

16

31

31

Noise Figure (dB) (a):

8.0

7.0

7.0

7.0

7.5

7.0

7.0

Output Level - Max (dBmV):

+36/+44

+36/+44

+36/+44

+36/+44

+36/+44

+36/+44

+36/+44

Test Port Level (dB):

Input:

NA

-20, ±2

-20, ±2

-20, ±2

NA

-20, ±2

-20, ±2

Output:

NA

-20, ±2

-20, ±2

-20, ±2

NA

-20, ±2

-20, ±2

Gain Control Range (dB):

15

15

15

15

15

15

15

Slope Control Range (dB):

10

10

10

10

10

10

10

Composite Triple Beat - CTB (dB) (b):

-65

-66

-72

-65

-61

-61

-66

Composite Second Order - CSO (dB) (b):

-65

-66

-68

-63

-59

-59

-64

Cross Modulation - XMOD (dB) (b):

-64

-64

-71

-63

-64

-64

-70

Hum Modulation (dB):

-70

-70

-70

-70

-70

-70

-70

Number of Hybrids:

1

2

2

2

1

2

2

Impedance - All Ports (Ohm):

75

75

75

75

75

75

75

Return Loss

Input (dB):

14

14

14

14

14

14

14

Output (dB):

14

14

14

14

14

14

14

RMDA 860-30 RMDA 860-30P RMDA 860-43P

RMDA 1000-30

RMDA 86A-30

Return Path

Frequency Range (MHz):

47-860

47-860

47-860

47-1000

47-860

5-40

Channel Loading:

129

129

129

152

129

5

Flatness (dB):

±1.00

±1.00

±1.00

±1.00

±1

±0.5

Hybrid Technology :

Push-Pull Power DoublingPower Doubling Push-Pull

Push-Pull

Gain (dB):

31

30

43

30

32

22(Active)

-1.5(Passive)

Noise Figure (dB) (a):

8.0

8.5

7.0

8.0

8.5

6

Output Level - Max (dBmV):

+34/+42

+36/+44

+36/+44

+30/+38

+34/+42

+48

Test Port Level (dB):

Input:

-20, ±2

-20, ±2

-20, ±2

-20, ±2

-30, ±2

-30, ±2

Output:

-20, ±2

-20, ±2

-20, ±2

-20, ±2

-30, ±2

-30, ±2

Gain Control Range (dB):

15

15

15

15

10

18

Slope Control Range (dB):

10

10

10

10

8

-

Composite Triple Beat - CTB (dB) (b):

-60

-62

-62

-67

-58

-66

Composite Second Order - CSO (dB) (b):

-64

-67

-67

-67

-59

-70

Cross Modulation - XMOD (dB) (b):

-57

-67

-67

-67

-58

-60

Hum Modulation (dB):

-70

-70

-70

-70

-70

-65

Number of Hybrids:

2

2

2

2

2 fwd, 1 rev

Impedance - All Ports (Ohm):

75

75

75

75

75

75

Return Loss

Input (dB):

14

14

14

14

14

15

Output (dB):

14

14

14

14

14

15

ORDERING INFORMATION

RMDA Model

Stock No.

Description

RMDA 550-30

5500 53

Rack Mounted Distribution Amplifier 30 dB, 47-550 MHz

RMDA 550-30P

5500P53

Rack Mounted Distribution Amplifier 30 dB, 47-550 MHz, Power Addition

RMDA 550-30S

5500S53

Rack Mounted Distribution Amplifier 30 dB, 47-450 MHz, Single Hybrid

RMDA 550-50

5500 55

Rack Mounted Distribution Amplifier 50 dB, 47-550 MHz

RMDA 750-30

5500 73

Rack Mounted Distribution Amplifier 30 dB, 47-750 MHz

RMDA 750-30P

5500P73

Rack Mounted Distribution Amplifier 30 dB, 47-750 MHz, Power Addition

RMDA 750-S15

5500S71

Rack Mounted Distribution Amplifier 15 dB, 47-750 MHz, Single Hybrid

RMDA 860-30

5500 83

Rack Mounted Distribution Amplifier 30 dB, 47-860 MHz

RMDA 860-30P

5500P83

Rack Mounted Distribution Amplifier 30 dB, 47-860 MHz, Power Addition

RMDA 860-43P

5500P84

Rack Mounted Distribution Amplifier 43 dB, 47-860 MHz, Power Addition

RMDA 1000-30

5500 13

Rack Mounted Distribution Amplifier 30 dB, 47-1000 MHz

RMDA-ARP Model

RMDA 86A-30

5200 83

860 MHz, 30 dB Push-Pull Amp with Active Return Path

VMI-CEQ8V

9377A-xx

Plug-in Equalizer, 860 MHz, Values 0-20 dB

VMI-AT

9320-xx

Plug-in Attenuator, 1000 MHz, Values 0-18 dB
