MICM Series
Micro Channel Modulator
Specifications
Video Connector:
“F” Female
Impedance:
75 Ω
Return Loss:
20 dB
Input Level:
1.0 volt Peak-to-Peak (87.5% depth of modulation)
Frequency Response:
1.0 dB Peak-to-Valley (fv to fv+4.2 MHz)
Peak to Peak Video-to-RMS
Hum Ratio:
64 dB
Signal-to-Noise Ratio:
65 dB (Weighted; 4 MHz bandwidth)
Differential Gain:
2.0% (87.5% depth of modulation)
Differential Phase:
2.0 degree (87.5% depth of modulation)
Chrominance/Luminance Delay:
Per FCC Requirements
Mono Audio (standard)
Connector:
RCA
Input Impedance:
Greater than 10 kΩ, unbalanced
Input Level:
(for 25 kHz deviation)
0.5 to 4.0 volt peak-to-peak (constant AGC range)
Frequency Range:
50 Hz to 12 kHz
Frequency Response:
± 0.5 dB
Total Harmonic Distortion:
1% @ 25 kHz deviation
Signal-to-Noise Ratio:
70 dB
Stereo Audio (optional)
Connector:
RCA
Input Impedance:
Greater than 10 kΩ, unbalanced
Input Sensitivity:
0.5 to 4.0 volt peak-to-peak
(for 55 kHz peak deviation)
(AGC Range with pilot tone)
Frequency Response:
+/-0.75 dB (50 Hz to 12 kHz)
Separation:
20 dB @ 50 Hz to 10 kHz
Connector:
“F” Female
Impedance:
75 Ω
Return Loss:
15 dB
Frequency Range:
54 to 550 MHz (NTSC CATV Ch. 2 -79 and
95-99)
Power Level:
+45 dBmV
Power Level Range:
10 dB continuously adjustable
Carrier-to-Noise:(In Channel)
63 dB
Broadband Noise:
-90 dBc (@ +45 dBmV output level, 4 MHz band.)
Spurious Outputs:
-66 dBc
Aural/Visual Carrier Ratio:
-11 to -19 dB continuously adjustable
4.5 MHz Aural Inter-carrier
Frequency Tolerance:
±250 Hz; 32 to 122 °F (0 to 50 °C)
Visual Carrier Frequency
Tolerance Standard Channels:
±10 kHz; 32 to 122 °F (0 to 50 °C)
FCC Aeronautical Channels:
±5 kHz; 32 to 122 °F (0 to 50 °C)
Front-Panel Indicators
Power:
Green LED
Stereo:
Red LED (when equipped)
Front-Panel Control
Output Level :
Potentiometer
Video Level:
Potentiometer
Audio Level:
Potentiometer
Aural Carrier Level:
Potentiometer
INPUT
OUTPUT Modes 1 & 2
ALARMS / MONITORING / CONTROL
Dimensions (W x D x H)
MICM Modules:
1.0 x 7.78 x 3.5 inches (25 x 198 x 89 mm)
MIPS-12C Power Supply:
4.6 x 7.5 x 3.5 inches (106 x 191 x 89 mm)
MIRC-12V Chassis:
19 x 12.0 x 5.25 inches (483 x 305 x 133 mm)
Power
MIPS-12C Power Supply:
100-240 VAC; 50/60 Hz
Power Dissipation:
~ 3 W (per MICM Module)
Weight
MICM Module:
0.65 lbs (0.3 kg)
Fully Loaded Chassis:
18.2 lbs (8.3 kg)
Operating Temperature:
32 to 122 °F (0 to 50 °C)
Storage Temperature:
-13 to 158 °F (-25 to 70 °C)
Operating Humidity:
0 to 95% RH @ 35 °C max, non-condensing
Storage Humidity:
0 to 95% RH @ 35 °C max, non-condensing
GENERAL
