Toner Cable AM Series Agile Modulators - Manual

AM Series
Agile Modulator
969 Horsham Road l Horsham, Pennsylvania 19044 USA l Phone: 215-675-2053 Fax: 215-675-7543 l [email protected]
AM series is a family of frequency-agile analog audio/video modulators. AM-60-860, the flag-ship model,
is available in NTSC channels 2-135 (54-860 MHz), and the PAL B, G, and I channels in the same fre-
quency range.
More economical models are available in NTSC for the frequency ranges 54-550 MHz, or 54-806 MHz.
EAS (Emergency Alert System) is standard on all models. Stereo Audio, SAP (Secondary Audio
Programming), and several other optional features are also available.
Ordering Information
Model Stock # Description
AM-60-860 59415A Frequency-agile Audio/Video Modulator, +60 dBmV, 54-860 MHz (NTSC)
AM-60-860-BG B59415A Frequency-agile Audio/Video Modulator, +120 dBμV, 47-860 MHz (PAL)
AM-60-806 59419 Frequency-agile Audio/Video Modulator, +60 dBmV, 54-806 MHz (NTSC)
AM-60-550 59416 Frequency-agile Audio/Video Modulator, +60 dBmV, 54-550 MHz (NTSC)
AM-45-550 59404 Frequency-agile Audio/Video Modulator, +45 dBmV, 54-550 MHz (NTSC)
Options
AM-OPT-02 BNC Video Input Connector
AM-OPT-04 Sub-Band Output (Available with AM-60-550 only)
AM-OPT-05 Integrated BTSC Stereo Audio
AM-OPT-06 SAP Audio/ BTSC Stereo (Available with AM-60-860 only)
AM-OPT-07 Video AGC
AM-OPT-08 Audio AGC
AM-OPT-09 Balanced Audio Input, 600 Ohm (Standard on AM-60-860)
