Toner Cable DSU-2 DSU Series 5-900 MHz Splitters User Manual
Dsu series, 900 mhz splitters
Specifications Subject To Change Without Notice
Rev 0
5-13
© Toner Cable Equipment, Inc.
DSU Series
5-900 MHz Splitters
DSU Series 5-900 MHz Splitters
DSU-2
2 Way DC Power Pass
DSU-2DC 2 Way DC Power Pass 1 Port
DSU-3
3 Way DC Power Pass
DSU-4
4 Way DC Power Pass
DSU-8
8 Way DC Power Pass
SPECIFICATIONS
DSU-2 &
DSU-3
DSU-4
DSU-8
DSU-2DC
Frequency
2-Way
3-Way
4-Way
8-Way
(MHz)
Typ
QA
Typ
QA
Typ
QA
Typ
QA
Insertion
5-300
2.8
3.0
5.3
5.5
6.7
69.
10.1
10.3
Loss
300-450
3.0
3.2
5.8
6.1
7.2
7.5
10.8
11.2
IN-OUT
450-600
3.3
3.5
6.0
6.3
7.5
7.8
11.3
11.8
(dB Max.)
600-900
3.5
3.8
6.2
6.5
7.8
8.1
12.0
12.6
Return 5-300
12
10
12
10
12
10
12
10
Loss
300-450
14
12
15
10
15
12
13
11
INPUT
450-600
15
12
15
10
13
11
14
12
(dB Min.)
600-900
12
10
13
11
11
10
12
10
Return
5-300
12
10
15
12
15
12
12
10
Loss
300-450
15
13
13
11
12
11
15
13
OUTPUT
450-600
13
11
12
10
11
10
15
13
(dB Min.)
600-900
12
10
11
10
12
11
13
11
Isolation
5-300
25
22
23
20
24
20
25
22
OUT-OUT
300-450
28
25
30
25
25
22
26
23
(dB Min.)
450-600
26
24
25
23
24
22
24
22
600-900
25
22
24
22
23
20
24
20
Power Pass
500 mA
One Port or All Ports
Impedance
5-900
75 Ohm
RFI (dB)
5-900
85 dB
