Input Frequency Range
Off Air mode: 54 to 806 MHz, CH 2 - 69
CATV modes: 54 to 860 MHz, CH 2 - 135
Recommended Input Levels
8VSB: -26 to +30 dBmV
64QAM & 256QAM: -12 to +15 dBmV
Connector & Impedance
Type F, 75 Ohms, 6 dB or better return loss.
Demodulation
Modulation and Symbol Rates Accepted: 8VSB @ 10.762 Ms/s
64 QAM (ITU B) @ 5.057 Ms/s
256QAM (ITU B) @ 5.3606 Ms/s
Equalizer span: - 75 to + 75 µSec
ASI Output - DAD860A only
Complete transport stream is output containing all programs
that are present on the RF channel that is being demodulated
Video
Output Format: 480i NTSC Video, 1 V p-p
Aspect ratio: The DAD860 provides choices for displaying a received HD
picture in the 480i NTSC output. Usually a cropped or a letter
box setting is chosen. Active Format Description, or AFD,
may be selected to allow broadcaster to control output format
Closed Captioning: YES. EIA-608 analog(VBI) closed captioning in the output
Video Output Connector: Type F female
Audio
Audio channel selection: YES, when multiple channels are provided
Output level: Approximately 250 mV rms, user programmable
Audio Output Connectors: RCA, two - left and right channels
Other
Power: DAD860: 5 V @ 390 mA and 12V @ 220 mA
DAD860A: 5V @ 550 mA and 12V @ 260 mA
Power supplied by PSM121 or RMM4 power supply
Operating Temp. Range: 0 deg C to + 50 deg C
FCC: Meets FCC, Part 15 requirements.
Specifications
DAD860
Digital to Analog Decoder
