Toner Cable Omega Non-Standby Power Supply - Manual (Page 2)

©Toner Cable Equipment, Inc. Specifications Subject To Change Without Notice.
Telephone: Nationwide: Fax: E-mail: Internet:
Ome
ga Non-Standby P
o
w
er Suppl
y
215-675-2053 800-523-5947 215-675-7543 [email protected] http://www.tonercable.com
ORDERING INFORMATION
PART #
DESCRIPTION
OM-115/60-06 6 Amp 60 VAC Economy Power Supply*
OM-115/60-09 9 Amp 60 VAC Economy Power Supply*
OM-115/60-15 15 Amp 60 VAC Economy Power Supply*
OM-115/60-25 15 Amp 60-90 VAC Economy Power Supply**
* LED Light and Lock are ordered as options
** LED Light, Lock, Digital Volt Meter, Generator Outlet, Internal Breaker 115V
are ordered as options
Contact us for additional models and information
on the International 220 Volt Power Supplies
OPTIONS
PART #
DESCRIPTION
OMEGA-TDR Time Delay Relay
OMEGA-LED LED Light
OMEGA-MTR Digital Volt Meter
OMEGA-GEN Generator Outlet
OMEGA-LOK Lock
OMEGA-WMB Wall Mount Bracket
OMEGA-BKR-115 Internal Breaker 115V
SPECIFICATIONS
Parameter
Value
Dimensions (in) 10L x 15H x 9.125W
Weight (lb) approx. 50 lbs. (pending configuration)
Material G-90 Hot Dipped Galvanized Steel
Finish Powder Coat
Color Grey
INPUT
Parameter
Value
Voltage Range ±15%
Frequency Range ±3%
OUTPUT
Parameter
Value
Wave Shape Quasi - Square Wave
Regulation ±3%
Overload Capacity 150% of Rated Maximum
Recommended Load 80% of Rated Maximum
Operating Efficiency 92% of Normal Load
ENVIRONMENT
Parameter
Value
Operating Temperature -40°C to +55°C
Relative Humidity 0 to 95% Non-Condensing
AVAILABLE CONFIGURATIONS
AC Input Voltage
115V or 220V
AC Input Frequency 50 Hz or 60 Hz
AC Output Current 3, 6, 9, 15 Amps
AC Output Voltage 60 V or 60/90V
Omega Non-Standby Power Supply Specifications
