ENC-300-HDSDI
H.264 MPEG-4 AVC HD/SD Encoder Blade & Portable Device
ENCODING SPECIFICATION:
Video inputs:
SD/HD/3G-SDI input: 0,8 V
P-P
, 75 Ohm (BNC, embedded audio support), (SMPTE259M, SMPTE292M, SMPTE424M);
Breakout cable inputs:
Composite, S-Video, Component and VGA
Video encoding:
H.264 (MPEG-4 AVC Part 10; ISO/IEC 14496-10). Profiles: Baseline, Main, High
Video encoding bitrates:
250Kb/s – 14Mb/s, CBR/VBR, low latency support
Video resolutions:
1920x1080p 30/29.97/25Hz, 1920x1080p 60/59.94/50Hz (with 2:1 frame converter) 1920x1080i 60/59.94/50Hz,
1280x720p 60/59.94/5030/29.97/25Hz, 720x480/576i 60/59.94/50Hz
VGA (RGB) resolutions:
1280x1024 60Hz, 1024x768 60Hz, 800x600 60Hz
Audio inputs:
1x stereo, unbalanced, AC-coupled
Audio nominal level: -10 dBV (0,316Vrms), maximum level: 2 V
P-P
Microphone nominal level: -60 dBV (1mVrms), gain control for microphone and line input
SDI embedded audio 2CH (SMPTE 272M, SMPTE 299M)
Audio encoding:
MPEG-4 AAC LC (ISO/IEC 14496-3), 48 kHz, 16Bit Sample Rate, 16-576 kbit data rate
Audio outputs (TALKBACK): 1x stereo, unbalanced, AC-coupled
Output gain adjustment from (off) -78 dB to +9 dB
TALKBACK: 16 bit stereo, PCM, sample rate 48kHz, 22,05 kHz
Multiplex format:
ISO/IEC 13818-1 Transport, ISO/IEC 14496-10 NAL (Network Abstraction Layer)
Stream types: transport stream and elementary audio/video stream
Scaling:
Downscaling from 720p and 1080i to 720, D1 or CIF, adjustable frame rate divider
Additional features:
Logo inserter for SD and HD. Presets can be saved, downloaded and uploaded
I/O SPECIFICATION:
Network:
10/100TX Ethernet, RJ45, half/full duplex, auto-sensing or manual control
Streaming traffic:
Unicast and multicast traffic supported, up to max. 5 output streams/destinations
IP protocols:
HTTP, TCP/IP control protocol, UDP/RTP/TCP streaming, IGMP, SAP, unicast/multicast, SNMPv2, DHCP
Error correction:
Pro-MPEG FEC (forward error correction) and TCP
KLV metadata:
NATO standard STANAG 4609, MISB standard 0603.1, 0604.2, 0605.3, SMPTE 12M-2
RS-232
:
RS-232 connection via console (remote control for non IP devices via TCP/IP serial command tunnelling)
GPIO:
1x In, isolated, 1x Out, isolated (FR-610)
MANAGEMENT:
Web browser, SNMP, Telnet and RS-232, software updates via web browser
Fault measurement with log generation, authorization via user password, RTC (Real Time Clock) support
ENVIRONMENTAL:
Agency approvals:
CE, RoHS, EN 55103-1, EN 55103-2, EN 55022
Humidity:
Up to 90%, non-condensing
Temperature:
-35 to +50°C and +60°C up to 5 hours environment temperature; fanless when operated as –PORTABLE
Blade weight:
Approx. 160 grams
Blade dimensions (H/W/D):
20mm x 130mm x 190mm, Europe Card (160mm x 100mm, 3HE), conform to IEC60297-3/-4
PORTABLE weight:
Approx. 690 grams
PORTABLE dimensions:
(H/W/D) 28mm x 105mm x 192mm
Power:
5Vdc ± 5% / 8W per blade
Limited Warranty:
1 year standard limited warranty. Warranty extensions for up to 5 years available
ORDER INFORMATION:
ENC-300-HDSDI
MPEG-4 AVC H.264 SD/HD encoder blade with SD/HD SDI input (with embedded audio) and Composite*, S-Video
(Y/C), Component (YP
b
P
r
) or analog VGA (RGB) input
ENC-300-HDSDI-Portable
MPEG-4 AVC H.264 SD/HD portable encoder device with SD/HD SDI input (with embedded audio)
and Composite, S-Video (YC), Component (YP
b
P
r
) or analog VGA (RGB) input
300-UPG-FEC
Upgrade option for ENC-/DEC-300-Series for forward error correction
300-UPG-KLV
Upgrade option for ENC-/DEC-300-Series for KLV metadata insertion
BREAKOUT-CABLE-S
YC (miniDIN), Composite (RCA jack), analog audio in/out (RCA jack). RCA plug to 3.5 mm phone jack adapter.
Breakout cable S is included in delivery
BREAKOUT-CABLE-P-3E
Composite/YC/YP
b
P
r
/RGBHV (all BNC female), analog audio in/out (RCA jack), RS-232 (Sub-D 9-pin), GPI connectors
(Sub-D 9-pin)
BREAKOUT-CABLE-VGA
RGBHV, analog audio in/out (RCA jack) connectors
FR-610
1RU Rack mount chassis for max. 6 blades
FR-610-DPS
1RU Rack mount chassis for max. 6 blades with redundant power supply
FR-2000-24
4RU Rack mount chassis for up to 21 blades (depends on blade combination) with redundant power supply
COMPLEMENTARY PRODUCTS:
DEC-300-HDSDI
H.264 HD & MPEG-2 HD decoder blade with HD-SDI-, embedded audio, analog video/audio output.
XPLAYER
PC Live stream playback software. Licence packages are available
MC-ROUTE-1RU
1RU appliance for live UDP, TCP, FEC, RTSP and HLS streaming and unicast/multicast bridging
***PLEASE NOTE: Live streaming/multicast streaming requires specially designed and configured networks. Minimum requirements
include: Layer-3 switched ethernet, multicast enabled, IGMPv2/3, network and multicast routing supported.
