Toner Cable PLM860SAW 860 MHz Channelized PLL SAW-Filtered A-V Modulator User Manual
Pcm55saw, Plm860saw, 550 mhz channelized pll saw-filtered a/v modulator

Specifications Subject To Change Without Notice
Rev 01-12
©Toner Cable Equipment, Inc.
969 Horsham Road
l
Horsham, Pennsylvania 19044 USA
l
Phone: 215-675-2053 Fax: 215-675-7543
l
PCM55SAW
550 MHz Channelized PLL SAW-Filtered A/V Modulator
PLM860SAW
860 MHz Channelized PLL SAW-Filtered A/V Modulator
Features
•
55dBmV minimum output for a 64dB in-
band carrier to noise ratio provides
superior picture quality (PCM55SAW)
•
82 Channel frequency range
54~550MHz (CATV 2~13, A1~A5,
A~PPP (PCM55SAW)
•
55dBmV minimum output for a 61dB in-
band carrier to noise ratio provides
superior picture quality (PLM860SAW)
•
Frequency range 552~860MHz (CATV
79-135) (UHF 14-69) (PLM860SAW)
•
SAW filtered IF for superior adjacent channel performance enables drop-in channel expansion
•
BTSC Stereo compatible pre-emphasis disable switch provides pass-through for stereo signals
•
Front panel controls and test point enable easy setup and monitoring
•
IRC and HRC offsets available for frequency settings in systems using offset channels
•
Auxiliary AC outlet for convenience
•
Optional PAL format channels available
•
UL Approved
OUTPUT FREQUENCY RANGE
PCM55SAW 54~550MHz
PLM860SAW 552~860MHz
TUNING
Channelized
RF output Level
55dBmV
CARRIER TO NOISE (IN-BAND)
PCM55SAW 64dB
PLM860SAW 61dB
CARRIER TO NOISE (OUT-OF-BAND)
PCM55SAW
67dB
PLM860SAW 64dB
Spurious Output
>65dB
Video Frequency Response
±1.5dB
Video Signal to Noise
60dB
Audio Input Type
Monaural/MTS Baseband
Audio Frequency Response
50~15,000Hz
Video Input Connection
75Ω F-Female
AUDIO INPUT CONNECTION
PCM55SAW
10Ω F-Female Unbalanced
PLM860SAW
600Ω F-Female Unbalanced
RF Output Connection
75Ω F-Female
Voltage Input
115VAC
Power Output Receptacle
Yes
Dimensions
19˝ (W) x 3˝ (D) x 1.75˝ (H)
WEIGHT
PCM55SAW 3.6
lbs
PLM860SAW 3.9
lbs
Ordering Information
PCM55SAW
550 MHz Channelized PLL SAW-Filtered
A/V Modulator
PLM860SAW
Specify CATV or UHF
SPECIFICATIONS
Channel
Channel
