C860
Bi-Directional Combiner
Features
•
Broadband 5-1000MHz
•
Broadcast quality specifications for
unparalleled picture quality
•
Built in Return-Path Diplexer
•
Sub-band output port provides high iso-
lation VHF/UHF ingress-free return
path for CMTS and remote audio/video
application
•
>18dB return loss provides reduced
reflections for exceptional digital signal
performance
•
Directional coupler design provides improved carrier-to-noise, system performance and picture quality
•
High -50dB port to port isolation provides spurious carrier rejection and minimizes undesired channel interaction,
thereby reducing picture distortion
•
Passive design allows bi-directional flexibility for two-way digital and analog requirements
•
Plug-in equalizers and attenuators (included) enable uniform gain and slope system balancing for minimum distor-
tion
•
-20dB test port provides convenient access for headend testing and system monitoring
RF INPUT
Frequency Range (fwd)
54-1000MHz
Frequency Range (rev)
5-42MHz
ISOLATION 54-1000MHZ
Adjacent >
40dB
Opposing >
50dB
Return Loss
-18dB
Impedance 75Ω
Test Point
-20 ±3dB
RF OUTPUT
FREQUENCY RANGE
Fwd 54-1000MHz
Rev 5-42MHz
INSERTION LOSS
5-42MHz 1.8dB
max
54-550MHz 28dB
max
551-1000MHz 31dB
max
FLATNESS
5-42MHz ±0.5dB
54-550MHz ±1.0dB
551-1000MHz ±1.5dB
Return Loss
-18dB
Impedance 75Ω
Test Point
-20 ±3dB
GENERAL
Dimensions
19˝ (L) x 12˝ (D) x 1.75˝ (H)
Weight 3.8
lbs.
Connectors “F”
type
Ordering Information
C860
Bi-Directional Combiner
SPECIFICATIONS
