Toner Cable SQM1200 12 RF Channel GbE_ASI Input Edge QAM User Manual
Sqm1200, 12 rf channel gbe/asi input edge qam, Features

Specifications Subject To Change Without Notice
Rev 10-11
©Toner Cable Equipment, Inc.
969 Horsham Road
l
Horsham, Pennsylvania 19044 USA
l
Phone: 215-675-2053 Fax: 215-675-7543
l
GbE INPUTS
Input Connector Type
2 x RJ-45
Layer 1 Ethernet
GbE (1000Base-T)
Layer 2 Addressing/Protocols Unicast (IP address and Port),
Multicast
MPEG Transport
SPTS/MPTS (ITU13818-1)
DVB-ASI INPUT
Input Connectors
4 x 75Ω BNC
Format Per
EN50053-9
Return Loss
-15dB
ETHERNET COMMUNICATION MANAGEMENT PORT
Input Connector Type
1 x RJ-45
Layer 2 Ethernet
10/100Base-T
Layer 4 Protocol
TCP/IP
QAM-RF OUTPUT
Output Frequency
Range 50-1002 MHz
RF Channels
Twelve (6 or 8 MHz)
QAM Modulation Modes
16, 32, 64, 128, 256
QAM Types
ITU-A (DISH/DVB), ITU-B (USA/DCII)
QAM Symbol Rates
2.24~2.98, 4.85 to 7.0 Msps
PCR Re-Stamping
Auto
Output Level
(effective, per channel)
>45 dBmV
(combined, 12 channel)
>32 dBmV
Output Attenuation
0-10 dB (0.5 dB step)
Output Level Flatness (50-1002 MHz)
±0.75 dB
Spurious >60
dBc
Output Connector 1 x 75Ω, F-Female
Output Return Loss >15 dB
GENERAL
INTERNAL AC POWER SUPPLY
Line Voltage
93-254 VAC, 47-63 Hz
Power Consumption
40 W
EXTERNAL DC POWER BACKUP
Voltage 12VDC±5%
VAC
Current <6A.
ORDERING INFORMATION
SQM1200
12 RF Channel GbE/ASI Input Edge QAM
X-PS
External Redundant Power Supply
SPECIFICATIONS
SQM1200
12 RF Channel GbE/ASI Input Edge QAM
Features
•
Accepts a GbE IP input, clear or pre-encrypted
unicast or multicast
•
Supports a total output of 12 QAM-RF channels
organized as 3 independent blocks of 4 chan-
nels
•
Provides four ASI inputs for content not avail in
IP format
•
Provides additional GbE port for redundant
inputs, alternate source or loop-through
•
Provides a 10/100Base-T Ethernet management
port
•
Integrated web server allows local or remote
access from a PC with standard Internet
browser
•
Web pages provide simple, easy navigation of
all status and setup parameters
•
Highly integrated 1RU rack mount with low
power consumption and low temperature rise
•
Support for external DC redundant powering
