Indoor optical node, Specifications – Toner Cable TIN40-1000 Indoor Optical Node User Manual
Page 2
Specifications Subject To Change Without Notice
Rev 11-11
©Toner Cable Equipment, Inc.
969 Horsham Road
l
Horsham, Pennsylvania 19044 USA
l
Phone: 215-675-2053 Fax: 215-675-7543
l
FORWARD
Optical Performance
Wavelength
1200-1600 nm
Operational AGC
Standard
Input Optical Power Range
AGC is operational within -6 to +2 dBm
Optical Input Test Point
1 V/mW, external, with calibrated power meter
Optical Input LED
3 color
RF Performance
Bandwidth
40-1000 MHz
Gain Flatness
± 1 dB
Gain Control
0 to 18 dB
Output Return Loss
≤ -14 dB
Test Point
-20 dB
Link Performance (0 dBm optical input
power, NTSC77 channel, OMI = % 3,8)
Output Level
40 dBmV min (stable from -6 to +2 dBm optical
level due to AGC)
CNR
52 dBc
CSO
62 dBc
CTB
62 dBc
ELECTRICAL & PHYSICAL PERFORMANCE
Surge Withstand
IEEEC62.41 Cat.A3 (6kV, 200A)
Powering - External Adaptor
12 VDC external power supply, connection with F type
connector (DC powering)
Powering Over Coax
Yes
Power Consumption
4, 0 Watt
Temperature
0 to 55°C
Enclosure
Aluminum diecast housing (IP54)
Weight
1.7 lbs (700 gr)
Dimensions
5.5 x 5.5 x 1.7 inches (140 x 140 x 44 mm)
Specifications
TIN40-1000
Indoor Optical Node
