ASI Inputs
Inputs:
Six Asynchronous Serial Inputs (ASI).
270 Mbps ASI clock rate with maximum transport stream of 40 Mbps
at each input.
MPTS or SPTS
QAM Modulator
Modulation Modes:
16QAM, 32QAM, 64QAM, 128QAM, 256QAM,512QAM or 1024QAM.
Refer to manual for available combinations of QAM modes and FECs.
Symbol Rate:
1 Ms/s to 7 Ms/s.
Forward Error Correction (FEC):
ITU-A (DVB) or ITU-B (DigiCipher® II)
I/Q Phase Error:
Less than 1 degree
Carrier Suppression:
45 dB
Channel Amplitude Error:
Less than 1dB
MER:
Greater than 38 dB with blind equalizer
Null Packet Processing
Fixed output clock mode
Upconverter RF Output
Output Frequency Range:
54 MHz to 1002 MHz
Channel Plan:
Standard CATV, HRC, IRC or Broadcast
Frequency Stability:
±5 ppm
Maximum Output Level:
+40 dBmV minimum, adjustable downward
Output Level Accuracy:
±1 dB
Output Impedance:
75 Ohms with return loss better than 14 dB
(within output filter passband)
Spurious Outputs:
-60 dBc from 40 MHz to 1000 MHz
Broadband Noise:
-75 dBc
Phase Noise:
-101 dBc @ 10 kHz offset
RS232 Control
Data Link:
2400, 4800, 9600, or 19,200 baud interface via serial cable
RS232 Input:
DB9 connector for connection to modem, PC,
or Drake SCTeci ethernet controller.
RS232 Output:
DB9 connector for connection to additional units
General
Power:
90-132 VAC, 60 Hz, 15 W maximum
Weight:
7 lbs. (3.2 Kg.)
Size:
19" (48.3 cm) W x 1.75" (4.45 cm) H x 11.5" (29.2 cm) D
Operating Temperature:
0º C (32º F) to 50º C (122º F)
Specifications
MQM6000L
Multiplexing QAM Modulator
