AQM
Agile QAM Modulator 1x ASI ► 1x QAM
Specifications
Connector:
BNC Female
Standard:
DVB-ASI; EN 50083-9
Transport Rate:
270 Mbps
Impedance:
75
Ω
Local Monitoring:
Front-panel 16-character, 2-line LCD screen
Local Control:
Front-panel Navigational Key-pad
Remote Monitoring/Control:
Not Available
INPUT
OUTPUT
ALARMS / MONITORING / CONTROL
Dimensions (W x D x H)
AQM Module:
2.3 x 7.5 x 3.5 inches (58 x 191 x 89 mm)
Power Supply:
4.6 x 7.5 x 3.5 inches (106 x 191 x 89 mm)
Rack Chassis:
19.0 x 12.0 x 3.5 inches (483 x 305 x 89 mm)
Power
MIPS-12C:
110 VAC/60 Hz
MIPS-12C PAL:
220 VAC/50 Hz
Power Dissipation:
5 W (per AQM module)
Weight
AQM Module:
2.3 lbs (1.04 kg)
Fully Loaded Chassis:
24.2 lbs (10.9 kg)
Operating Temperature:
32 to 122°F (0 to 50°C)
Storage Temperature:
-13 to 158°F (-25 to 70°C)
Operating Humidity:
0 to 95% RH @ 35°C max, non-condensation
Storage Humidity:
0 to 95% RH @ 35°C max, non-condensation
GENERAL
Connector:
“F” Female
QAM Modulation Modes:
16, 32, 64, 128, 256, 512, and 1024
DVB Symbol Rate:
Variable; 1 to 10 MSymbols/sec (MBaud)
Frequency Range:
5.75 to 864 MHz
QAM Tuning:
NTSC:
Per channel’s number from 2 to 135 & T7 to T14
PAL:
Per channel’s center-frequency
(12.5 kHz increments)
RF Level:
+40 dBmV (100 dB
μV)
RF Level LCD Screen Error:
±2 dB
RF Level Adjustment Range:
30 to 40 dBmV
Frequency Tolerance:
±0.5 kHz @ 77°F (25°C)
Frequency Stability:
±5 kHz over 32 to122°F (25°C)
Amplitude Flatness:
±0.25 dB (over 6 MHz channel)
Phase Noise:
-98 dBc (@ 10 kHz)
Spurious:
-60 dBc
Broadband Noise:
-75 dBc (@ +40 dBmV output level,
4 MHz bandwidth)
Impedance:
75
Ω
Return Loss:
12 dB
Spectral Inversion:
Auto Recognition
Carrier Suppression:
55 dB
SNR:
Greater than 40 dB
MER:
Greater than 40 dB
I/Q Phase Error:
Less than 1 degree
I/Q Amplitude Imbalance:
Less than 1%
