Trident7
®
IEEE 802.3 GEPON Optical Network Terminals
802.3 EFM (GEPON) ONT Specifications
Units ONT-E4020i ONT-E1320X ONT-E1321X ONT-E1321X-RTN ONT-E888X-RTN
Network Interface
Optical Interface SC/APC SC/APC SC/APC SC/APC SC/APC
Fiber Type Single-mode Single-mode Single-mode Single-mode Single-mode
Transmit Wavelength nm 1310 1310 1310 1310 1310
Mean Launch Power dBm +1 to +4 +1 to +4 +1 to +4 +1 to +4 +1 to +4
Receive Wavelength (Data) nm 1490 1490 1490 1490 1490
Receive Wavelength (RF Video) nm N/A N/A 1550 1550 1550
Receive Sensitivity @1310nm dBm -27 -26 -26 -26 -26
Receive Sensitivity @ 1550nm
(48 dB CNR, 3 EDFA Cascade,
78 Analog Cable TV channels)
dBm NA N/A -5 -5 -5
Receive Overload @ 1490nm dBm -3 -3 -3 -3 -3
Receive Overload @ 1550nm dBm NA N/A >+1 >+1 >+1
Narrowcast Data Rate Mbps 1250 1250 1250 1250 1250
Narrowcast Line Code 8B10B 8B10B 8B10B 8B10B 8B10B
Telephony
Analog POTS Lines 2 2 2 2 8
REN 5 5 5 5 5
Inside Wiring (Maximum) ft. 300 300 300 300 300
Data
Ethernet Ports
(Physical Connector)
(4)
10/100/1000BASE-
T (RJ-45)
(1) 1000BASE-T
(3) 10/100BASE-T
(RJ-45)
(1) 1000BASE-T
(3) 10/100BASE-T
(RJ-45)
(1) 1000BASE-T
(3) 10/100BASE-T
(RJ-45)
(8) 10/100BASE-T
(RJ-45)
Aggregate Data Throughput Mbps 1000 1000 1000 1000 800
RF Video
RF Video Ports
(Physical Connector)
0 0
1
(Female F-type)
1
(Female F-type)
8
(Female F-type)
RF Video Output Bandwidth MHz NA NA 54 - 1000 54 - 1000 54 – 1000
RF Output Level
(@ 870 MHz, 3.5% OMI)
dBmV NA NA +17 +/- 3 +17 +/- 3 +17 +/- 3
RF Output Tilt
(Nominal, 54-870 MHz)
dB NA NA +3 +3 +3
Optional RF Return NA NA N/A SCTE 55-1, DSG SCTE 55-1, DSG
Physical Characteristics
Dimensions (W x H x D) in. 9 x 1.5 x 6.2 8.9 x 10.9 x 2.9 8.9 x 10.9 x 2.9 8.9 x 10.9 x 2.9 11.75 x 15.5 x 8.5
mm 228 x 38 x 157.5 226 x 277 x 74 226 x 277 x74 226 x 277 x 74 298 x 394 x 216
Weight lbs. 1 5.6 5.6 5.6 21.6
kg .45 2.5 2.5 2.5 9.8
Operating Temperature F +32 to +113 -40 to +140 -40 to +140 -40 to +140 -40 to +140
C 0 to +45 -40 to +60 -40 to +60 -40 to +60 -40 to +60
Power
Input Voltage VDC 12 12 12 12 -48
Maximum Power Consumption W 5 11.5 13 13 36
Standby Power Consumption W NA <7 <7 <7 NA
Reliability
MTBF hrs. >200k >200k >200k >200k >200k
Availability % 99.99 99.99 99.99 99.99 99.99
969 Horsham Road l Horsham, Pennsylvania 19044 USA l Phone: 215-675-2053 Fax: 215-675-7543 l [email protected]
Trident7 ®
IEEE 802.3 GEPON Optical Network Terminals
Specifications Subject To Change Without Notice Rev 10-12 © Toner Cable Equipment, Inc.
