Specifications
TDA Series
CATV Distribution Amplifier
Model Forward GaAs-FET Push Pull Reverse
Frequency Range 54-1000 MHz 5-42 MHz
Gain 35 dB 18 dB
Flatness ±1 dB ±1 dB
Return Loss IN/OUT -16 dB -16 dB
RF Test Points -30 dB (Out) --
Gain Control, Variable -20 dB (Input) -20 dB (Output)
Slope Control, Variable IN -20 dB -20 dB
Performance
79 Channels @ 34/46 dBmV Output:
CTB -63 dBc --
CSO -70 dBc --
XMOD -62 dBc --
135 Channels @ 34/46 dBmV Ouput:
CTB -61 dBc --
CSO -67 dBc --
XMOD -60 dBc --
Reverse Distortion
4 channels (52 dBmV Flat Output):
3rd on T10 -- -68 dBc
2nd on T9 -- -65 dBc
Xmod on T10 -- -64 dBc
Noise Figure 7 dB 7 dB
Hum Modulation -70 dB
RFI Isolation -90 dB
Surge Withstand, IN/OUT IEEEC62.41 Cat.A3 (6kV, 200A)
Powering Plug-In Wall Type External Power Supply (+6VDC-1A),
available in 117/230 VAC
Power Consumption @117 VAC 0.095A, @220 VAC 0.045A
Temperature -10° to +55°C
Enclosure IP54 Category, Diecast Aluminum
Weight 3.75 lbs / 1.7 kgs
Dimensions 7 5/8" x 5 3/8" x 3" / 19.5 x 13.6 x 7.5 cm
Model Bandwidths
TDA35-1000/42 5-42 MHz / 54-1000 MHz
TDA35-1000/65 5-65 MHz / 80-1000 MHz
