HDE-CSV-QAM

MPEG-2 HD Encoder

1x Component / HD-SDI / HDMI / VGA / Composite ► 1x QAM

Specifications

Dimensions (W x D x H):

5.65 x 12.5 x 1.75 inches (144 x 317.5 x 44.5 mm)

Power:

External Power Supply (Input 115-230VAC /
Output 12VDC @ 3 Amp)

Power Dissipation:

20 W

Weight (one module):

1.5 lbs (0.7 kg)

Operating Temperature:

32 to 122 °F (0 to 50 °C)

Storage Temperature:

-13 to 158 °F (-25 to 70 °C)

Operating Humidity:

0 to 95% RH @ 35 °C max, non-condensing

Storage Humidity:

0 to 95% RH @ 35 °C max, non-condensing

INPUT

OUTPUT

GENERAL

Encoding Profile
Video

Output Format:

MPEG-2 HD MP@ML; ISO 13818-2

Chroma:

4:2:0

Resolution:

720x480; 1280x720; 1920x1080

Frame rate:

29.97 fps (480i); 29.97 fps (1080i); 59.97 fps (720p)

Aspect Ratio:

4:3 & 16:9

GOP Structure:

I & P frames (user-selectable)

Transport Rate:

Variable (user-selectable)

Video Bit Rate:

Variable (user-selectable)

Video Pre-filter:

Variable (user-selectable)

Intra DC Precision:

Variable; 8-11 bit (user-selectable)

Color Space:

YCbCr and RGB

Audio

Output Format:

Dolby® Digital AC-3

Sampling rate:

48 kHz

Bit rate:

Variable; 96 - 448 Kbps (user-selectable)

Closed Captioning

Component:

EIA- 608; 1x RCA (CC)

HD-SDI:

EIA-708; Embedded in HD-SDI input

HDMI:

EIA- 608; 1x RCA (CC)

Composite:

EIA- 608

QAM

Connector:

1x “F” Female (Rear-panel)

Modulation:

QAM 16, 32, 64, 128, and 256

Standards:

ITU-T J.83; Annex A and B

DVB Symbol Rate:

Variable; up to 7 MSymbol/sec (MBaud)

Frequency Range:

54 to 1002 MHz

Tuning:

CATV Channel Selectable (Ch. 2 to 158)

Channels’ Bandwidth:

6 MHz

RF Level:

+40 dBmV ±1 dB

RF Level Adjustment:

+32 to +42 dBmV, 1 dB increment

Frequency Tolerance:

± 0.5 kHz @ 77 °F (25 °C)

Frequency Stability:

± 5 kHz over 32 to 122 °F (0 to 50 °C)

Amplitude Flatness:

± 0.25 dB (over 6 MHz channel)

Phase Noise:

-98 dBc (@ 10 kHz)

Spurious:

-60 dBc

Broadband Noise:

-70 dBc (@ +35 dBmV output level,
5.5 MHz bandwidth)

Impedance:

75 Ω

Spectral Inversion:

Auto Recognition

Carrier Suppression:

45 dB

Return Loss:

14 dB typical

Signal-to-Noise Ratio (SNR):

40 dB typical

MER:

40 dB typical

I/Q Phase Error:

Less than 1 degree

I/Q Amplitude Imbalance:

Less than 1%

ASI

Connectors:

1x BNC (Front-panel)

Format:

DVB-ASI

Standard:

ETSI EN 50083-9

Connector:

1x RJ45 (Front-panel)

Standard:

10/100Base-T Ethernet

UDP/RTP:

Supported (user-selectable)

Component

Connectors:

3x RCA for Video (Y, Pb, Pr)
2x RCA for Analog Audio (L, R)
1x RCA for Digital Audio (PCM)

Video Resolution:

480i, 720p, & 1080i

Video Aspect Ratio:

4:3 & 16:9

HD-SDI

Connector:

1x BNC

Standard:

SMPTE 292M

Video Resolution:

480i, 720p, & 1080i

Audio:

Embedded PCM and pass-through
Dolby® Digital only

HDMI

Connector:

1x HDMI

Video Resolution:

480i, 720p, & 1080i

HDCP Encryption:

Not supported

Audio:

Embedded PCM & pass-through
Dolby® Digital only

VGA

Connectors:

2x Female VGA (Input + Loop-through Output)

Video Resolution:

640x480 @ 60 fps
800x600 @ 60 fps
1024x768 @ 60 fps

Audio:

2x RCA for Analog Audio (L, R)
1x RCA for Digital Audio (PCM)

Composite

Connectors:

1x RCA for Video (Y)

Video Resolution:

480i

Audio:

2x RCA for Analog Audio (L, R)
1x RCA for Digital Audio (PCM)

Local Monitoring:

1x Status LED
1x Power LED

Local Control:

1x IP Reset button

Remote Monitoring/Control:

GUI-based menu via Web browser
(1x RJ45 front-panel connector; 10/100Base-T,
also used for IP output)

ALARMS / MONITORING / CONTROL
