Specifications Subject To Change Without Notice

Rev

10-12

© Toner Cable Equipment, Inc.

969 Horsham Road

l

Horsham, Pennsylvania 19044 USA

l

Phone: 215-675-2053 Fax: 215-675-7543

l

[email protected]

ITU-T G.984 GPON ONT Specifications (Outdoor ONTs)

Units

ONT-G4021

ONT-G1321

ONT-G888

Network Interface

Optical Interface (Class B+/C+)

SC/APC

SC/APC

SC/APC

Transmit Wavelength

nm

1310

 20

1310

 20

1310

 20

Mean Launch Power

dBm

+0.5 to +5

+0.5 to +4

+0.5 to +4

Receive Wavelength (Data)

nm

1490

 10

1490

 10

1490

 10

Receive Wavelength (RF Video)

nm

1555

 5

1555

 5

1555

 5

Receive Sensitivity @ 1490nm

dBm

-28 wo FEC

-27

-27

Receive Sensitivity @ 1555nm
(48 dB CNR, 3 EDFA Cascade,
78 Analog Cable TV channels)

dBm

-5 -5 -5

Receive Overload @ 1490nm

dBm

-8 -3 -3

Receive Overload @ 1555nm

dBm

+2 +2 +2

Narrowcast Upstream Rate

Mbps

1244 1244 1244

Narrowcast Downstream Rate

Mbps

2488 2488 2488

Data

Ethernet Ports
(Physical Connector)

(4) 1000BASE-T

(RJ-45)

(1) 1000BASE-T

(3) 10/100BASE-T

(RJ-45)

(8) 10/100BASE-T

(RJ-45)

Aggregate Data Throughput

Mbps

1000 1000 800

Telephony (Optional)

Analog POTS Lines

0 or 2

0 or 2

8

REN

5

5

5

Inside Wiring (Maximum)

ft. 300

300

300

RF Video (Optional)

RF Video Ports
(Physical Connector)

0 or 1

(Female F-type)

0 or 1

(Female F-type)

0 or 8

(Female F-type)

RF Video Output Bandwidth

MHz

54 - 1000

54 - 1000

54 - 1000

RF Output Level
(@ 870 MHz, 3.5% OMI)

dBmV

+17 +/- 3

+17 +/- 3

+17 +/- 3

RF Output Tilt
(Nominal, 54-870 MHz)

dB +3

+3

+3

Optional RF Return

SCTE 55-1, DSG SCTE 55-1, DSG SCTE 55-1, DSG

Physical Characteristics

Dimensions (W x H x D)

in.

8.9 x 10.9 x 2.9

8.9 x 10.9 x 2.9

11.75 x 15.5 x 8.5

mm

226 x 277 x 74

226 x 277 x 74

298 x 394 x 216

Weight

lbs. 5.6

5.6

21.6

kg 2.5

2.5

9.8

Operating Temperature

F

-40 to +140

-40 to +140

-40 to +140

C

-40 to +60

-40 to +60

-40 to +60

Power

Input Voltage

VDC

12 12 -48

Maximum Power Consumption

W 13

13

36

Standby Power Consumption

W

<7 (POTS)

<7 (POTS)

NA

Reliability
MTBF

hrs.

>200k >200k >200k

Availability

% 99.99

99.99

99.99

Trident7

®

ITU-T G.984 GPON Optical Network Terminals
