Specifications Subject To Change Without Notice

Rev 10-10

©Toner Cable Equipment, Inc.

969 Horsham Road

l

Horsham, Pennsylvania 19044 USA

l

Phone: 215-675-2053 Fax: 215-675-7543

l

[email protected]

Input/Output

Component YPbPr or RGB
3 x BNC connectors
RCA supported via adaptors
HDMI digital input with HDCP
Terminal block audio connector for
Balanced and Un-Balanced Stereo
RCA Stereo Audio
RJ-45 Ethernet 10/100
RJ-45 Serial RS-232C or RS-422

Video Encoding

HD Video h.264 MPEG-4 AVC
Compression
High Profile at level 4 (HP@L4)
5Mbps to 20Mbps
SD Video h.264 MPEG-4 AVC
Compression
Main Profile at Level 3 (MP@L3)
2Mbps to 20Mbps

Video Resolutions

1080p 24
1080i 59.94/60
1080i 50
720p 59.94/60
720p 50
576i 50
480i 59.94

Audio Encoding

MPEG-1 Layer II stereo
128kbps to 384kbps
MPEG-2 AAC stereo
128kbps to 384kbps

Dimensions

(W x D x H)
40 x 131 x 175 (1.6” x 5.2” x 6.9”)

Weight

225g (approximate)

Power Input

4.25 Watts
MPP200 Chassis 100-240VAC
50/60Hz Adapter
MPP1700 Chassis 100-240VAC
50/60Hz

Environmental

Operating Temperature -10ºC to
50ºC (14ºF to 122ºF)

Compliance

CE, UL Listed I.T.E. E257717
EMC: EN55022 Class B (MPP200)
Class A (MPP1700)
Safety: EN60950, IEC60950

Specifications

AVN441HD

H.264 High Definition Encoder Blade
