Specifications Subject To Change Without Notice

Rev 03-11

©Toner Cable Equipment, Inc.

969 Horsham Road

l

Horsham, Pennsylvania 19044 USA

l

Phone: 215-675-2053 Fax: 215-675-7543

l

[email protected]

AVAILABLE FORMATS

INPUTS

ASI:

(2) BNC up to 160Mb/s

DVB S/S2/DSNG:

(4) F- Type (A/B)
QPSK, 16QAM, 8PSK,
16APSK, VCM,ACM,ISI filtering
(advanced/license - able)

LNB Power:

13,18VDC, 22KHz tone
1-45Msym/s
950-2150 MHz

MPEGoIP:

(2)10/100/1000 Base-T, RJ45
Encapsulation type- UDP and RTP
Unicast/Multicast (IGMPv3)
ProMPEG CoP3r2 FEC/SMPTE2022

Conditional Access:

BISS 1/E
DVB-CI- (2) Slots,

Control: Front

Panel

Web Interface-IE7 and up,
Firefox3.0 and up
SNMPV2 with traps

DECODER

Video:

MPEG2- MP@ML (4:2:0)
MPEG2- HP@ML (4:2:0)
H.264 - [email protected]
PAL, NTSC

Max TS Bitrate:

160Mb/s

Display Modes:

Letterbox, cropped, anamorphic
AFD(SMPTE2016)

Audio:

(2) audio pair (decode, embed and
pass-through both compressed and
decoded formats)
AES
MPEG2
MPEG1
AC-3
DD+
DolbyE
Linear PCM
HE-AAC v2 ISO/IEC 14496-3:2005/
Amd.2(Including HE-AAC 7.1,
LOAS,ADTS)
PCM Downmix (selectable): L/R
(Stereo), Lt/Rt (Surround), Mono1,
Mono2

OUTPUTS

SDI:

(2 BNC) ITU-BT.601/SMPTE 259M
Embedded Audio Format:

SMPTE272M

Number of Embedded Audio Channel

Pairs:

4 (2 complete audio groups)
Embedded Audio Types- MPEG-2,-1,
AC3,DD+, DolbyE, PCM, HE-AAC
Embedded CC- EIA-708B

Display Modes:

Letterbox, cropped, anamorphic
Other Embedded Data Types:

Teletext, WSS,VPS
(EN301775 embedded per
SMPTE2031)
VITC,AMOL I-II,TV Guide
(SCTE127 embedded per
SMPTE2031)
AFD (SMPTE2016)
VBI Insertion- Teletext,
WSS,VPS,VITC,AMOL I-II,TV
Guide, V-Chip

Composite:

(1) BNC- NTSC/PAL
Overlay closed caption selectable
Line21 CC Insertion-EIA-608B
VBI Insertion- Teletext,
WSS,VPS,VITC,AMOL I-II,TV Guide,
V-Chip

Audio:

(2) BNC (selectable)
(2) Stereo pair (balanced,terminal
connector)
AES
MPEG2
MPEG-1
AC-3
DD+
DolbyE
Linear PCM
HE-AAC v2 ISO/IEC 14496-3:2005/
Amd.2(Including HE-AAC 7.1,
LOAS,ADTS)
PCM Downmix (selectable): L/R
(Stereo), Lt/Rt (Surround), Mono1,
Mono2

ASI:

(1) BNC up to 160 Mb/s

MPEGoIP:

(2)10/100/1000 Base-T, RJ45
Encapsulation type- UDP and RTP
Unicast/Multicast (IGMPv3)

Specifications

IRD 3030/3035/3040/3045

Integrated Receiver Decoder

MODEL INPUT OUTPUT
IRD-3030 DVB-S2 Composite
IRD-3035 DVB-S2 SDI
IRD-3040 IP

Composite

IRD-3045 IP

SDI
