Specifications

Specifications Subject To Change Without Notice

Rev 12-11

©Toner Cable Equipment, Inc.

969 Horsham Road

l

Horsham, Pennsylvania 19044 USA

l

Phone: 215-675-2053 Fax: 215-675-7543

l

[email protected]

The AD-1 is a professional quality agile
audio/video demodulator. The unit pro-
vides audio and video outputs from any
analog input channel in the 54 to 88
and 108 to 806 MHz frequency range.
The AD-1 is ideal for signal monitoring
and signal conditioning (audio/video
processing and remodulation) applica-
tions. Agile channel selection permits
on-the-fly channel changes.

The AD-1 takes a single NTSC channel
in the 54 to 88 and 108 to 806 MHz fre-
quency range and demodulates the
audio and video information. Baseband
audio and video as well as 4.5 MHz
audio subcarrier and mulitplex audio
are provided as outputs. The AD-1 fea-
tures phase locked loop synthesized
frequency control with a tuning incre-
ment of 250 kHz. Channel selection is
accomplished with the use of simple to
use front panel accessible dip switches.
A Nyquist filter provides stable, accu-
rate demodulation of the vestigial side-
band signal. Additionally, this filter mini-
mizes distortion and preserves the tim-
ing of the signal. Delayed AGC circuitry
automatically compensates for input
signal variations. The AD-1 also utilizes
a quasi-synchronous video detector that
has low differential gain and minimal
phase distortion. A quadrature audio
detector delivers a very low distortion
audio output. The broadband multiplex
audio, 4.5 MHz audio subcarrier, or the
optional BTSC stereo (L/R) or SAP out-
puts make the AD-1 ideal for any stereo
application.

Ordering Information

Model Stock

#

Description

AD-1B

5932

Agile Audio/Video Demodulator 54-88 MHz/108-806 MHz

Options

AD-1-OPT 17

59257

AD-1 Option: Sub-Band Input, 7-49 MHz

AD-1-OPT 20

59250

AD-1 Option: Digital Control, Serial RS-232

AD-1-OPT 25

59255

AD-1 Option: Stereo Audio Output, 600 

Ω Balanced

AD-1-OPT 29

59259

AD-1 Option: Balanced Audio, 600

Ω

RF

Input Frequency Range:
Standard: 54-88 & 108-806 MHz
Option 17: Sub-band Input: 7-49 MHz
Channels: VHF, UHF (Input) CATV

(STD,HRC,IRC)

Tuning Increment: 250 kHz
Input Level - Max: +20 dBmV
Noise Figure

VHF: 8-11 dB
UHF: 10 dB

Image Rejection - Min

VHF: 65 dB
UHF: 50 dB

Input/Output Impedance: 75

Ω

Video

Frequency Response: fv+25 Hz to fv+4.0 MHz -

Settable to ±1.0 dB

Output Level:

1.0 V p-p

Differential Gain: 3.0 %
Differential Phase: 1.5 °
Group Delay Response: ±50 ns
Output Impedance: 75

Ω

Output Return Loss: 25 dB

Audio

Mono

Baseband Frequency Response:

50 Hz to 15 KHz: ± 0.75 dB

Output Level:

500 mV RMS (Opt 29, 1.4 V RMS)

Impedance: 600

Ω

, Unbalanced (STD)

(Opt. 29, 600

Ω

, Balanced)

Audio Signal-to-Noise: 57 dB
Total Harmonic Distortion: 0.6%
Multiplexed Frequency Response:

50 Hz to 100 kHz: ±0.2 dB

Output Level: 500 mV RMS
Impedance: 600

Ω

, unbalanced

Stereo (Option 25)

Baseband Frequency Response 50 Hz to 12 KHz

(in-phase L/R inputs): ± 0.75 dB

Output Level Left or Right: 4.0 Vp-p

Impedance: 600

Ω

, Balanced

Separation 50 Hz – 10 KHz: 20 dB
Audio Signal-to-Noise: 60 dB
Total Harmonic Distortion: <0.5%
4.5 MHz Subcarrier Output Level: +28 dBmV
Impedance: 75

Ω

General

Power Requirements

Voltage: 117, ±10% VAC
Frequency: 60 Hz

Power: 16 W
Fuse: 1/4 A
Temperature Range: 0 to +50 °C

Mechanical

Dimensions (WxHxD):

19.0 x 1.75 x 14.5 in.
483 x 44 x 368 mm

Weight: 5.5 lbs., 2.50 kg

Connectors

RF Input

Standard - VHF/UHF: "F" Female
Option 17: Sub-band Input: "F" Female

Video Output: "F" Female
Baseband Audio Output:

RCA Phono, Female (STD)
Terminal Strip (Opt 25 + 29)

Multiplexed (MPX) Audio Output:

RCA Phono, Female (STD Only)

4.5 MHz Subcarrier Audio Output:

"F" Female

Serial Data Input & Output:

Option 20: Serial Input: RJ-12, Female

Controls

Frequency Selection:DIP Switches
Video Response: Control
Sub-band Input Channels Option 17:

Slide Switch

L/R or SAP Audio Output Option 15:

Contact Closure

Indicators

Power ON: LED, Green
Stereo: LED, RED (Opt 25)

AD-1 Series

Analog Agile Demodulator
