Parameter Value
System
MPEG-2/DVB Compatible
EN300 421, EN 300 468
Demodulation
DVB-S QPSK, DVB-S2 QPSK
and 8PSK
Tuner
Number of RF Inputs 4 (one active at a time)
Input Level 25 dBm to -65 dBm per carrier
Frequency Range 950 MHz to 2150 MHz
Symbol Rate Range DVB-S: 1.0 to 45 MSymbols/s
DVB-S2: 10.0 to 30 MSymbols/s
1.0 to 10 MSymbols/s
Carrier Capture Range ≥ ±3.0 MHz (1-10 Msym)
≥ ±5.0 MHz (10-30 Msym)
Satellites C-band and Ku-band
Input Impedance 75 Ω
Analog Outputs
Analog SD Video Output
Number of Channels
One down-converted source
HD program
Video Decompression Type MPEG-4 4:2:0
Output Level 1.0 V pp ±5%
Output Impedance 75 Ω
Analog Audio Output
Number of Channels
Two stereo pairs/four mono channels
Audio Decompression MPEG or Dolby Digital (AC-3)
Transcoder Channel Inputs
HD Video Input
Compression Format
MPEG-4 part 10
V Resolutions 1080, 720
H Resolutions 1080i: 1920, 1440
720p: 1280, 960
Input Bit Rate 3 Mb/s to 20 Mb/s main profile
3 Mb/s to 25 Mb/s high profile
Audio Input
Number of Channels
Two audio channels
Compression Format MPEG or Dolby Digital (AC-3)
VBI Data Input
Transmission Format
EIA-708 and 608
Transcoder Channel Outputs
HD Video Output
Compression Format
MPEG-2
V Resolutions Same as input
H Resolutions 1080i: 1920, 1440
720p: 1280, 960
Output Bit Rate 10 Mb/s to 25 Mb/s
Parameter Value
Down-Converted SD Video Output
Compression Format
MPEG-2
V Resolutions 480, 576
H Resolutions 720/704/544/528
Output Bit Rate 2 Mb/s to 15 Mb/s
SD Output Aspect Ratios 4:3, 16:9
Aspect Ration Conversions 4:3: 16:9 Letterbox
14:9 Letterbox, Center Cutout
16:9 Center Cutout
Audio Output
Number of Channels
Two audio channels
Compression Format Same as input
VBI Data Output
Transmission Format
EIA-708 and 608
Inputs/Outputs
MPEG-2 Transport Input EN50083-9, DVB-ASI coaxial,
188/204 byte packets
MPEG-2 Transport Output EN50083-9, DVB-ASI coaxial,
188 byte packets
MPEGoIP Output
Ethernet Type
1000 Base-T
Format UDP/IP or RTP
IP Addressing Multicast
TS Streaming MPTS
Other Outputs
Cue Trigger Output
Number of Outputs
8
Type Open collector
Cue Tone Output
Balanced Audio Output
-3.0 dBu ±3 dB, 600 Ω
Output Impedance < 50 Ω
Programmable Relay Output Alarm or configurable to one of the
8 open collector outputs
Environmental/Physical
Operating Temperature 0°C to 50°C (32°F to 122°F)
Storage Temperature -20°C to 70°C (-4°F to 158°F)
Physical Dimensions 1.75 H x 19.0 W x 20.5 D in
(4.4 H x 48.3 W x 52.1 D cm)
Weight 16 lbs (7.2 kg) approx.
Power
Voltage Range 100 to 240 VAC
Line Frequency 50/60 Hz
Power Consumption 110 W max
LNB Power on RF #1 +13V/+18V @ 400 mA max
Specifications
D9858
Advanced Receiver Transcoder
