IPAT IP - ASI Transcoder Specifications

©Toner Cable Equipment, Inc.

Specifications Subject To Change Without Notice.

Telephone:

Nationwide:

Fax:

E-mail:

Internet:

Blonder T

ongue IP

A

T

IP-ASI T

ranscoder

215-675-2053

800-523-5947

215-675-7543

[email protected]

http://www.tonercable.com

IP Input/Output Interface

Connector:

1 x RJ45

Format:

Gigabit Ethernet (GbE)

Standard:

IEEE 802.3 10/100/1000 Base-T Ethernet

Protocols:

IPv4, RTP/UDP, ARP, IGMPv2, ICMP

ASI Input/Output Interface

Connector:

1 x BNC

Format:

DVB-ASI, 270 Mbps

Standard:

ETSI EN 50083-9

Connector In/Out:

“F” Female/BNC

INPUT

8VSB:

ATSC Digital Television Standard A/53E

QAM:

ITU-T J.83 (64 and 256 QAM)

8VSB Mode

Tuning Range:

UHF

(NTSC Ch. 14-78)

, VHF

(NTSC Ch. 2-13)

Symbol Rate:

10.762 Msymbols/sec

Bandwidth:

6 MHz

QAM Mode

Tuning Range:

CATV

(NTSC Ch. 2-135)

Symbol Rate:

5.3606 Msymbols/sec (QAM 256);
5.057 Msymbols/sec (QAM 64) - Auto Detect

Bandwidth:

6 MHz

Single Channel Power Level:

-32 to +45 dBmV

8VSB Power Level:

-20 to + 30 dBmV

QAM Power Level:

-20 to +20 dBmV

Return Loss:

12 dB

Impedance:

75

Ω

OUTPUT

Format:

DVB-ASI, 270 Mbps

Standard:

ETSI EN 50083-9

Dimensions (WxDxH):

19.0 x 18.125 x 1.75"
(483 x 460 x 44 mm)

Power:

117 to 230 VAC/50 to 60 Hz
(Fuse: 2.0 amp, 250 VDC, Slo Blo)

Power Dissipation:

Less than 40 W

Weight:

6 lbs (2.7 kg)

Operating Temperature:

32 to 122°F (0 to 50°C)

Storage Temperature:

-13 to 158°F (-25 to 70°C)

Operating Humidity:

0 to 95% RH @ 35°C max,
non-condensing

Storage Humidity:

0 to 95% RH @ 35°C max,
non-condensing

Indicators:

Power

(1x Green LED)

IP/ASI Input/Output Status

(2x Green LEDs)

RF IN/RF OUT Module Status

(2x Green LEDs)

Monitoring/Control:

GUI-based menu via Web browser
Front-panel RJ-45 interface
(10/100 Base-TX Ethernet)

INPUT

RF IN Module (Optional)

GENERAL

ALARMS / MONITORING / CONTROL

Connector In/Out:

BNC/“F” Female

INPUT

Format:

DVB-ASI, 270 Mbps

Standard:

ETSI EN 50083-9

OUTPUT

QAM Modulation Modes:

16, 32, 64, 128, 256, 512, and 1024

DVB Symbol Rate:

Variable; 1 to 10 MSymbols/sec (MBaud)

Frequency Range:

5.75 to 864 MHz

QAM Tuning:

Per NTSC ch. from 2 to 135 & T7 to T14
Per PAL ch. center-frequency

(12.5 kHz increments)

RF Level:

+40 dBmV (100 dB

μV)

RF Level LCD Screen Error:

±2 dB

RF Level Adjustment Range:

30 to 40 dBmV

Frequency Tolerance:

±0.5 kHz @ 77°F (25°C)

Frequency Stability:

±5 kHz over 32 to 122°F (0 to 50°C)

Amplitude Flatness:

±0.25 dB (over 6 MHz channel)

Phase Noise:

-98 dBc (@10 kHz)

Spurious:

-60 dBc

Broadband Noise:

-75 dBc (@ +40 dBmV output level,
4 MHz bandwidth)

Impedance:

75

Ω

Return Loss:

12 dB

Spectral Inversion:

Auto Recognition

Carrier Suppression:

55 dB

SNR:

Greater than 40 dB

MER:

Greater than 40 dB

I/Q Phase Error:

Less than 1 degree

I/Q Amplitude Imbalance:

Less than 1%

RF OUT Module (Optional)
