System
2x1 Gbps network interfaces
1 downstream interface per system
2 upstream interfaces per system
DOCSIS Features
Full DOCSIS 3.0 compliant
Full EuroDOCSIS 3.0 compliant
DOCSIS 3.0 downstream channel bonding
from 2 to 8 channels
DOCSIS 3.0 upstream channel bonding
from 2 to 8 channels
DOCSIS 3.0 AES encryption/decryption
DOCSIS 3.0 IPv6
DOCSIS 3.0 Multicast
Complete DOCSIS/EuroDOCSIS 1.1 features
DOCSIS/EuroDOCSIS 2.0 A-TDMA
PacketCable 1.5 compliant
PacketCable MultiMedia
DSG
L2VPN
IP Features
DHCP Relay & option 82
Multiple DHCP servers
Proxy ARP
IP subnet bundling
Static IP routing
Multiple default routes
IGMP snooping
IGMP v2 & v3
Access control list
BGP, RIPv2, OSPFv2 & IS-IS PIM-SM
L2VPN VLAN tagging
GigE Interfaces
Dual SFP f iber/copper 1 GigE
CWDM
Full line-rate support
Management
RS232 Serial port (RJ45)
Command line interface (CLI)
Telnet & SSH
SNMPv1, v2 & v3
Standard DOCSIS & IETF MIBs
IPDR
Casa Systems Enterprise MIBs
Event logging through syslog
Electronic mail notification
Resource usage reporting
TACACS+ & RADIUS
DOCSIS QAM Interface
Number of ports 1 port per system
Number of channels 2-8 channels per port
QAM modulation Annex A, B or C
QAM constellations 64, 128 & 256 QAM
Data rates (DOCSIS) 27 Mbps @ 64 QAM
38 Mbps @ 256 QAM
Data rates 36 Mbps @ 64 QAM
(EuroDOCSIS) 51 Mbps @ 256 QAM
Connector F-Type, 75
Ω
Frequency range 48 to 999 MHz (standard)
(center)
Frequency accuracy
+/- 5 ppm
Frequency step size 5 kHz
Channel width 6 to 8 MHz
(tunable)
Maximum output 61 dBmV @ 1-ch/port
power per channel 57 dBmV @ 2-ch/port
53 dBmV @ 4-ch/port
Output step size 0.1 dB
Return loss 50 ~ 870 MHz, 14 dB
870 ~ 1002 MHz, 10 dB
Modulation error rate 43 dB (equalized)
Wideband noise -73 dBc
Additional Features
Dynamic upstream & downstream load balancing
Spectrum management
Software-defined MAC domains
Software channel licensing
Ingress cancellation filtering
DOCSIS Upstream Interface
Number of ports 2 ports per system
Number of channels 1-4 channels per port
Logical channels 2 logical per physical
channel
Modulation QPSK, 8, 16, 32 & 64 QAM
Data rate per channel 0.32 – 30.72 Mbps
Input frequency range 5 – 42 MHz (DOCSIS)
5 – 65 MHz (EuroDOCSIS)
5 – 55 MHz (J-DOCSIS)
Connector F-Type, 75
Ω
Input range -4 to 26 dBmV
Mechanical
Form Factor 1RU
Height 1.75 in. / 4.4 cm
Width 8.75 in. / 22.2 cm
Depth 15 in. / 38.1 cm
Weight 6 lbs / 2.72 kg
Mounting 19 in., 1 rack unit high
Front Panel LED Power, alarm
Environmental
Operating Temperature 0° to 50° C
Storage Temperature -40° to 70° C
Operating Humidity 5% to 95%, non-cond.
Power Supply 110 to 240 V
AC operating range (Dual external)
Power consumption < 80 W (max)
Regulatory Compliance
Safety: UL/CSA/EN60950-1
EMC: FCC Part 15, Subpart B
EN55022
EN55024
C1G
(DOCSIS 3.0 Release)
Cable Modem Termination System
Specifications
