Toner Cable DSU Series 1GHz 80dB EMI MATV Power Passing Splitter User Manual
Dsu series, 1ghz 80db emi matv power passing splitter, Features

Specifications Subject To Change Without Notice
Rev 11-11
©Toner Cable Equipment, Inc.
DSU Series
1GHz 80dB EMI MATV Power Passing Splitter
969 Horsham Road
l
Horsham, Pennsylvania 19044 USA
l
Phone: 215-675-2053 Fax: 215-675-7543
l
Features
•
Broadband 5~1000MHz frequency range
•
High-performance printed board circuitry provides improved hum modulation and intermodulation parameters
to ensure superior signal quality (DSU-P Series)
•
Yellow-chromate plated zinc-alloy diecast housing ensures excellent ground bonding and long corrosion-free
service life in indoor/outdoor applications
•
Epoxy-sealed back cover provides effective EMI-RFI shielding >-80dB, eliminating signal ingress to provide
distortion-free pictures
•
1-inch centered 3⁄8˝ long precision machined F-connector threads ensure improved port-to-connector inter-
face and accommodate external security devices
•
High retention seizing pins provide improved connectivity to connector center lead
Ordering Information
DSU-2P
2-Port 1GHz Power Passing Splitter
DSU-3P
3-Port 1GHz Power Passing Splitter
DSU-4P
4-Port 1GHz Power Passing Splitter
DSU-8P
8-Port 1GHz Power Passing Splitter
MS-2D
2-Port 1GHz Power Passing Splitter
DSU-2P
DSU-3P
MS-2D
DSU-8P
DSU-4P
MHz
DSU-2P
DSU-3P
DSU-4P
DSU-8P
Isolation Input/Output
RFI
Insertion Loss
Insertion Loss
Insertion Loss Insertion Loss
(min dB)
Return Loss
(max dB)
(max dB)
(max dB)
(max dB)
(min dB)
5-400
3.6
3.7/7.2
7.2
11.0
20
18
>80 dB
400-500
3.8
3.9/7.5
7.5
11.0
24
18
>80 dB
470-600
4.0
3.9/7.5
7.5
12.0
23
18
>80 dB
600-1000
4.0
4.4/8.2
8.2
12.9
20
18
>80 dB
Specifications
