System
4x2 Gbps switching capacity
MPEG switching from any port to any port
Four DOCSIS interface slots per system
1~3 Downstream modules per system
1~3 Upstream modules per system
DOCSIS Features
Full DOCSIS 3.0 Qualified (May, 2008)
Full Euro-DOCSIS 3.0
DOCSIS 3.0 downstream channel bonding
up to 16 channels
DOCSIS 3.0 upstream channel bonding up
to 16 channels
DOCSIS 3.0 AES encryption/decryption
DOCSIS 3.0 IPv6
DOCSIS 3.0 Multicast
Complete DOCSIS/EuroDOCSIS 1.1
features
DOCSIS/EuroDOCSIS 2.0 A-TDMA
(standard)
DOCSIS/EuroDOCSIS 2.0 S-CDMA
(optional)
PacketCable 1.5 qualified
PacketCable MultiMedia (PCMM) 1.0
DSG
IP Features
DHCP Relay and option 82
Multiple DHCP servers
Proxy ARP
IP subnet bundling
Static IP routing
Multiple default routes
IGMP snooping
IGMP v2 and v3
Access Control List
RIPv2
BGP
OSPFv2
PIM-SM
L2VPN VLAN tagging
IS-IS
Management
RS232 Serial port (DB9)
10/100BaseT management port
Command Line Interface (CLI)
Telnet and SSH
SNMPv1, v2, and v3
Standard DOCSIS and IETF MIBs
IPDR
Casa Systems Enterprise MIBs
Event logging through Syslog
Electronic mail notification
Resource usage reporting
TACACS+ and RADIUS
Additional Features
Dynamic upstream and downstream load
balancing
Spectrum Management
Software-defined MAC domains
Software channel licensing
Ingress cancellation filtering
MPEG Stream Processing
MPEG de-multiplexing and re-multiplexing
Unicast to Multicast conversion
PAT and PMT extraction and regeneration
PID filtering and remapping
PCR jitter removal and re-stamping
SI table generation and insertion
DVB Simulcrypt scrambling
Session-based Encryption
GbE Interfaces
10/100/1000 Mbps
4-port copper or fiber SFP
CWDM
Full line-rate support
DOCSIS QAM Module (DQM)
Number of ports 4 ports per module
DQM08 8 channels,
2 channels per port
DQM16 16 channels,
4 channels per port
QAM modulation Annex A, B or C
QAM constellations 64, 128, & 256 QAM
Data rates (DOCSIS)
27 Mbps @ 64 QAM
38 Mbps @ 256 QAM
Data rates (EuroDOCSIS)
36 Mbps @ 64 QAM
51 Mbps @ 256 QAM
Connector F-type, 75 Ω
Frequency range 91 to 867 MHz (standard)
(center) 48 to 999 MHz (optional)
Frequency accuracy +/- 5 ppm
Frequency step size
5 kHz
Channel width 6 to 8 MHz (tunable)
Maximum output 61 dBmV @ 1-ch/port
power per channel 57 dBmV @ 2-ch/port
53 dBmV @ 4-ch/port
Output step size 0.1 dB
Return loss 50 ~ 870 MHz, 14 dB
870 ~ 1002 MHz 10 dB
Modulation error rate
43 dB (equalized)
Wideband noise -73 dBc
DOCSIS Control and Upstream Module (DCU)
DCU04 4 channels in 4 ports
DCU08 8 channels in 8 ports
DCU16 16 channels in 8 ports
Modulation QPSK, 16, 32 & 64 QAM
Data rate per channel
0.32 – 30.72 Mbps
Input frequency range
5 – 42 MHz (DOCSIS)
5 – 65 MHz (EuroDOCSIS)
Connector F-type, 75 Ω
Input range -4 to 26 dBmV
Mechanical
Form Factor 1RU
Height 1.75 in. / 44.45 mm
Width 19 in. / 482.6 mm
Depth 23.5 in. / 597 mm
Weight 30 lbs / 13.62 kg
Mounting 19 inch, 1 rack unit high
Front panel LED Power, alarm, I/O status
Environmental
Operating temperature
0° to 50° C
Storage temperature
-40° to 70° C
Operating humidity
5% to 95%, non-cond.
Power supply
AC operating range: 90 to 264 V
(Option) DC: -36 to –60 V (redundant )
Power consumption < 400 W (nominal)
Regulatory Compliance
Safety: UL/IEC/CSA 60950-1
EMC: FCC Part 15 Class A and CISPR
Class A
Immunity: EN61000-4
C2200
(DOCSIS 3.0 Release)
Cable Modem Termination System
Specifications
