4 Port Tap Plate Specifications
MODEL TXMT104-26 TXMT104-23 TXMT104-20 TXMT104-17 TXMT104-14 TXMT104-11 TXMT104-8T
TAP VALUE 26 dB 23 dB 20 dB 17 dB 14 dB 11.5 dB 8 dB
BANDWIDTH — — — 5-1000 MHz — — —
COLOR CODE Blue Orange Black Purple Yellow Brown Green
TOLERANCE ± 1.5 dB ± 1.5 dB ± 1.5 dB ± 1.5 dB ± 1.5 dB ± 1.5 dB ± 1.2 dB
INSERTION LOSS TYP MAX TYP MAX TYP MAX TYP MAX TYP MAX TYP MAX TERMINATING
- 30 MHz 0.5 0.8 0.7 1.0 1.3 1.6 1.4 1.7 2.1 2.5 3.3 3.6 Terminating
30 - 150 MHz 0.4 0.7 0.6 1.0 1.2 1.6 1.2 1.5 2.3 2.6 3.2 3.6 Terminating
150 - 300 MHz 0.5 0.8 0.7 1.0 1.3 1.6 1.3 1.6 2.3 2.6 3.3 3.6 Terminating
300 - 450 MHz 0.5 0.9 0.8 1.1 1.4 1.8 1.4 1.8 2.4 2.7 3.4 3.8 Terminating
450 - 600 MHz 0.6 1.0 0.9 1.3 1.5 1.9 1.6 1.9 2.5 2.8 3.6 3.9 Terminating
600 - 750 MHz 0.7 1.1 1.0 1.3 1.6 2.0 1.7 2.0 2.6 2.9 3.5 3.9 Terminating
750 - 860 MHz 0.9 1.3 1.2 1.6 1.7 2.2 1.8 2.2 2.8 3.1 3.6 4.0 Terminating
860 - 1000 MHz 1.2 1.6 1.7 2.1 2.0 2.5 2.1 2.6 3.2 3.6 3.7 4.2 Terminating
RETURN LOSS (min)
TAP PORTS
10 - 30 MHz 25 25 25 25 25 25 25
30 - 600 MHz 20 20 20 20 20 20 20
600 - 1000 MHz 20 20 20 20 20 20 20
INPUT/OUTPUT
10 - 30 MHz 18 18 18 18 18 18 18
30 - 600 MHz 20 20 20 20 20 20 20
600 - 1000 MHz 18 18 18 18 18 18 18
TAP TO TAP ISOLATION
10 - 30 MHz 27 27 27 27 27 27 27
30 - 600 MHz 27 27 27 27 27 27 27
600 - 1000 MHz 27 27 27 27 27 27 27
NOTE: add a T to the tap plate model to order a Terminating version of the tap plate.
