Toner Cable T10 Drop Cable RG6 Series - Manual (Page 2)

©Toner Cable Equipment, Inc. Specifications Subject To Change Without Notice.
Telephone: Nationwide: Fax: E-mail: Internet:
Times Fiber T10 6 Series Dr
op Ca
ble
215-675-2053 800-523-5947 215-675-7543 [email protected] http://www.tonercable.com
PHYSICAL SPECIFICATIONS
NOMINAL DIMENSIONS STANDARD PREMIUM TRISHIELD QUADSHIELD
Braid Coverage % 60 90 60 and 77 60-40
inches (mm) inches (mm) inches (mm) inches (mm)
Conductor 0.0403 (1.02) 0.0403 (1.02) 0.0403 (1.02) 0.0403 (1.02)
Dielectric 0.180 (4.57) 0.180 (4.57) 0.180 (4.57) 0.180 (4.57)
Sealed APA Tape (1st Outer Conductor) 0.188 (4.78) 0.188 (4.78) 0.188 (4.78) 0.188 (4.78)
Aluminum Braid (2nd Outer Conductor) 0.212 (5.38) 0.212 (5.38) 0.212 (5.38) 0.212 (5.38)
Unsealed APA Tape (3rd Outer Conductor) -- -- -- -- 0.216 (5.49) 0.216 (5.49)
Aluminum Braid (4th Outer Conductor) -- -- -- -- -- -- 0.241 (6.12)
Jacket 0.273 (6.93) 0.273 (6.93) 0.278 (7.06) 0.297 (7.54)
Cable Width (Single)
Messenger Diameter (Single) 0.051 (1.30) 0.051 (1.30) 0.051 (1.30) 0.051 (1.30)
Single Messenger Width 0.428 (10.9) 0.428 (10.9) 0.433 (11.0) 0.452 (11.5)
Siamese Width 0.591 (15.0) 0.591 (15.0) -- -- 0.639 (16.2)
Messenger Diameter (Siamese) 0.072 (1.83) -- -- -- -- 0.072 (1.83)
Siamese Messengered Width 0.768 (19.5) -- -- -- -- 0.816 (20.7)
Messenger Break Strength Size Minimum Maximum
0.051 in (1.30 mm) 185 lb (823 N) 245 lb (1090 N)
0.072 in (1.83 mm) 365 lb (1624 N) 490 lb (2180 N)
Cable Weight [pounds per 1000 feet (kg/km)]
Regular 60 90 60 77 60-44
Single 28 (42) 29 (43) 28 (42) 29 (43) 33 (49)
Single Messengered 40 (60) 41 (61) 40 (60) 41 (61) 45 (67)
Siamese 57 (85) -- -- -- -- -- -- 66 (98)
Siamese Messengered 77 (115) -- -- -- -- -- -- 86 (128)
Underground
Single Flooded 27 (40) 29 (43) 29 (43) 30 (45) 31 (46)
Siamese Flooded 55 (82) 58 (86) -- -- -- -- 63 (94)
lifeTime TM
Single Flooded 27 (40) 29 (43) 29 (43) 30 (45) 31 (46)
Single Flooded Messengered 39 (58) 40 (60) 41 (61) 42 (63) 43 (64)
Siamese Flooded 55 (82) -- -- -- -- -- -- 63 (94)
Siamese Flooded Messengered 75 (112) -- -- -- -- -- -- 81 (121)
ELECTRICAL SPECIFICATIONS
Nominal DC Resistance at 68° F (20° C) Ohms per 1000 feet (ohms/1000 meters)
Braid Coverage % Standard Premium Trishield Quadshield
Conductors 60 90 60 77 60-40
Center Conductor 30.4 (100) 30.4 (100) 30.4 (100) 30.4 (100) 30.4 (100)
Outer Conductor 9.13 (30) 5.74 (18) 6.57 (21) 5.49 (18) 4.85 (16)
Loop 39.6 (130) 36.0 (118) 36.9 (121) 35.9 (118) 35.3 (116)
Nominal Capacitance-All Types 16.2 pF/ft (53.2 pF/m)
Impedance 75 ±3 Ohms
Velocity of Propagation 85% nominal
