B-NOVA Chassis
Sub module slots, hot swap
6
Fans replaceable
4
Dimensions h x w x d
44 mm x 483 mm x 385 mm
Operating temperature range
-10...+55 °C
Storage temperature range
-30...+70 °C
EMC compatibility
EN 50083-2
WEB Browser User Interface,
CLI and SNMP V2 & V3
IE7.0 or Mozilla Firefox 3.0
(or newer)
Power Supply, 110V … 230VAC
max 120 W
Streaming Ports
2x Gb Ethernet SFP
Management and Dataports
for Scrambling
2x RJ45
B-NOVA Receivers
Impedance, F-connector
75 ohm
Transport Stream Bitrates
per RF input w/o descrambling
90 Mb/s
descrambling in use
72 Mb/s
Satellite Receiver RF Input
Frequency Range
950 … 2150 MHz
AFC Range
8 MHz
Constellation
QPSK, 8PSK, 16APSK
FEC modes (auto-detected)
All ratios compliant with
ETS302307
Signal levels
-70 … -25 dBm
Symbol rate
QPSK 1,5…47 MS/s
8PSK 1,5…31,5
MS/s
16APSK 1,5…47
MS/s
Standard ETS300421,
ETS302307
Adjustable voltage
13/18 V
22 kHz tone
on/off
Max output current per connector 500 mA
Terrestrial Receiver RF input
Frequency Range
47 … 862 MHz
Constellation
QPSK, 16QAM, 64QAM
FEC modes (auto-detected)
All ratios compliant with
standard
OFDM spectrum
2k and 8k
levels
-90 … -20 dBm
Channel Bandwidth
6, 7, 8 MHz
Standard ETS300744
DBV ASI input
DBV ASI input
BNC 75 ohm
Maximum speed
per interface payload traffic
216 Mb/s
Maximum speed total
(4 ports shared)
250 Mb/s
Standard EN50083-9
DVB Common Interface Descrambling
Connector dual slots
PCMCIA
Standard DVB_CI
EN50221
CA module Hot Plug
PC-Card type II
DVB Common Scrambling
Algorithm Content Protection Scrambling Option
Max service to be scrambled
per module (dual Inputs)
120
quad inputs module
120
B-NOVA IP-Output
IP Streaming
DVB transport packets over
UDP/IP
Packet format
1…7
Traffic type
unicast or multicast
Maximum IP streamer
per module
120
Maximum streaming capacity
per module
250 Mb/s
Traffic shaping
max peak traffic limiter
IP Inputs
Frame formats
(1…7 TS packets per frame)
UDP/IP
Max inputs streams per module
128
De-jittering buffer size
(adjustable 100…500 ms)
200 ms
B-NOVA Output Modules Common Multiplexers
Number of multiplexers
per module
4
Max input service
per multiplexer
64
Max components per service
32
IP Streamer Output of Multiplexer
Framing format
raw UDP/IP
Traffic type
unicast or multicast
TS packets per UDP frame
1…7
Max TS packet speed
per streamer
100 Mb/s
Maximum speed total
(4 streamers)
250 Mb/s
DVB Common Scrambling Algorithm Content Protection
ext. CA-Server
Max service to be scrambled
per module
120
QUAD QAM
Output speed
(Four adj. Channels)
depends on QAM modulator
settings
Standard
ITU-T J.83 Annex A/C
QAM constellations
64, 128, 256
Symbol Rate
4…7,4 MS/s
Output Level
102 … 112 dBμV
Output center frequency
85 MHz … 1GHz
MER >43
dB
COFDM Output
Transmission mode
2K, 8K
Transmission Guard Interval
1/32, 1/16, 1/8, 1/4
QAM constellations
QPSK, QAM16, QAM64
Channel bandwidth
6, 7, 8 MHz
HO code rate
1/2 , 2/3, 3/4, 5/6, 7/8
Output Level
(Four adj. channels)
102 … 112 dBμV
Output Level accuracy
+/- 2 dB
Output Power step size
0,2 dB
Output center frequency
85 MHz … 1GHz
QUAD ASI Output / Multiplexer Module
Traffic mode (VBR or CBR)
adjustable
Output speed for constant bitrate adjustable 1…100 Mb/s
Maximum speed per interface
(payload traffic)
100 Mb/s
Maximum speed total
(4 ports shared)
250 Mb/s
Standard EN
50083-9
B-NOVA Professional Headend Solution Specifications
Specifications Subject To Change Without Notice
Rev 10-10
