Toner Cable MIRC-4CUBE-CH 4 Slot Vertical Micromod Chassis User Manual
Modular headend system, Rack chassis and power supply

Modular Headend System
Rack Chassis and Power Supply
969 Horsham Road
l
Horsham, Pennsylvania 19044 USA
l
Phone: 215-675-2053 Fax: 215-675-7543
l
Ordering Information
Model Stock
#
Description
MIRC-4D
7711
HE-4 Series Rack Chassis & Power Supply 19” Rack Mount
MIRC-12V
7715
HE-12 Series Vented Rack Chassis 19” Rack Mountable 2 RU Chassis for 12 Modular Units
MIPS-12C
7722C
HE-12 Series Power Supply 5.5 A on 5 VDC line, 4 A on 12 VDC line
MIRC-4CUBE-CH
7703
4 Slot Vertical Chassis Supports combinations of up to 4 MICM, AMCM or MIDM units
MIRC-4CUBE-PS
7702
4 Slot Vertical Chassis Power Supply Unit
Accessories
Model Stock
No.
Description
MIBP-1
7787
Blank Panel Insert Single Modular Panel compatible with HE-12 / MIRC-12 Chassis
MIBP-2
7788
Blank Panel Insert Dual Modular Panel compatible with HE-12 / MIRC-12 Chassis
MHF
7782
Modular Series Headend Fan
The MIRC-4CUBE is extremely well suited for use
in surveillance or security type applicatoins. A
video camera’s baseband video output can be
modulated to any cable television channel and
combined with existing TV signals to permit any
outlet to monitor the camera feeds. This compact
chassis can support up to 4 fixed channel or agile
modulators and can be mounted in pratically any
location. The use of Blonder Tongue high perfor-
mance modulators easily permits placing camera
signals on adjacent channels.
Specifications
General
Power Requirements:
100 VAC to 240 VAC, ±10%
Frequency:
50 to 60 Hz
Temperature Range:
0° to +50° C
Output: +5 VDC @ 5.5 Amps, +12 VDC @4 A, 75 W
Mechanical
Dimensions (WxHxD) :
4.16” x 3.5” x 7.50”
Weight:
1.10 lbs (0.50 kg)
Connectors
AC In put:
IEC
DC Output:
37 pin D
Indicators
Power: LED,
Green
Accessories Supplied
AC Power Cable: 6 Ft, IEC, USA
Specifications
General
Power Requirements:
100 VAC to 240 VAC
Frequency:
50 to 60 Hz
Temperature Range:
0° to +50°C
Output Voltage & Current Capacity:
+12 VDC @ 1.8 Amps
+5 VDC @ 1.8 Amps
MIRC-4D 4 Slot Vertical Chassis
MIRC-12V 12 Slot Horizontal Chassis
MIRC-4 CUBE
MIPS-12C Power Supply
MHF Headend Fan
