PBN EPON-ONU & 4100 Light Link

®

Dir

ect

215-675-2053

800-523-5947

215-675-7543

[email protected]

http://www.tonercable.com

Optical Interface
EPON Standard:

IEEE802.3ah

Operating wavelength

CATV:

1550 nm ± 5 nm

Data RX:

1490 nm ± 10 nm

Data TX:

1310 nm ± 20 nm

CATV input

Range:

-8 ~ 0 dBm @ 1550 nm

Nominal

-5 dBm @ 1550 nm

Data RX sensitivity:

< -24 dBm @ 1490 nm

Data RX saturation:

>-3 dBm @ 1490 nm

Data TX output:

-1 ~ 4 dBm @ 1310 nm

Line speed

Downstream:

1.25 Gbps

Upstream:

1.25 Gbps

Optical connector:

SC/APC, E2000/APC

Fast Ethernet Subscriber Ports
Interface:

Auto-negotiation,

10/100 Mbps, full/half duplex

IEEE802.1D:

64 MAC addresses per

Ethernet port

IEEE802-1Q:

VLAN mapping to LLID

IEEE802.1P:

7 priority queues with

L2/L3/L4 classification

Frame size:

64...1522 bytes

Data security:

Supports 128-bit AES

Logical Link IDs:

3 x LLID

Connectors:

2 x RJ-45

(1)

VoIP Subscriber Port (Option)
VoIP:

SIPv2

Voice codecs:

G.711, G.726, G.729, 723.1

Features:

Call conferencing, Call forwarding,

Caller ID, Call waiting, DTMF,

Echo cancellation, Fax-tone detection

pass-through, Silence suppression, VAD

VoIP connectors:

2 x RJ-11 (POTS)

CATV Subscriber Port (Option)
RF output:

(2)

18 dBmV

RF frequency:

45 ~ 862 MHz

RF flatness:

± 1 dB

RF connector:

SCTE F-type

CATV Link Performance

(2)

42 CENELEC channels (as per EN50083-3)

CNR:

> 48 dB

CSO:

>55 dBc

CTB:

>61 dBc

110 NTSC channels (as per FCC standard)

CNR:

>49 dB

CSO:

>55 dBc

CTB:

>61 dBc

General
Power input

Mains:

16 Vac, 1.5 A

External battery:

11 ~ 15 Vdc

Power consumption

CATV receiver:

2.7 W

Fast Ethernet node:

3.4 W

Voice adapter:

4.0 W

External battery:

Sealed lead-acid 13.8 V,

7 Ah (8 hr uptime

(3)

)

Operating temperature:

-10 ~ 60°C

Storage temperature:

-20 ~ 70°C

Dimensions (HxWxD)

Indoor unit:

170 x 256 x 47 mm

Outdoor unit:

220 x 263 x 83 mm

Ship size (HxWxD)

Indoor unit:

245 x 350 x 80 mm

Outdoor unit:

220 x 263 x 110 mm

Weight

Indoor unit:

0.8 kg

Outdoor unit:

1.6 kg (excluding battery)

Ship weight

Indoor unit:

1.2 kg

Outdoor unit:

2.0 kg (excluding battery)

EPON-ONU Light Link

®

Direct Specifications

Optical Interface
EPON Standard:

IEEE802.3ah

Operating wavelength

CATV:

1550 nm ± 5 nm

Data RX:

1490 ± 10 nm

Data TX:

1310 ± 20 nm

CATV input (option)

Range:

-8 dBm to 0 dBm @ 1550 nm

Nominal:

-5 dBm @ 1550 nm

Data RX sensitivity:

< -24 dBm @ 1490 nm

Data RX saturation:

> -3 dBm @ 1490 nm

Data TX output:

-1 dBm to 4 dBm @ 1310 nm

Line speed

Downstream:

1.25 Gbps

Upstream:

1.25 Gbps

Optical connector:

4100, 4100V

SC/PC - blue – flat polished

4100T, 4100VT

SC/APC - green – angle polished

Fast Ethernet Ports
Interface:

Auto-negotiation, 10/100Mbps,

full/half duplex

IEEE802.1D:

64 MAC addresses per Ethernet port

IEEE802.1Q:

VLAN mapping to ports

Frame size:

64 to1522 bytes

Data security:

Supports 128-bit AES

Connectors:

4 x RJ-45

CATV Port (Option)
RF output:

18 dBmV (1)

RF frequency:

45~870 MHz

RF flatness:

± 1 dB

RF connector:

SCTE F-type

CATV Link Performance (1)
42 CENELEC channels (as per EN50083-3)

CNR:

> 48 dB

CSO:

> 55 dBc

CTB:

> 61 dBc

79 NTSC CW channels + Digital

CNR:

> 49 dB

CSO:

> 55 dBc

CTB:

> 61 dBc

Phone FXS Ports (Option)
VoIP:

SIPv2

Voice algorithms:

G.711, G.726, G.729A,

G.723.1, Dynamic pay load

Features:

Call transfer, Call conferencing, Call

fowarding, Caller ID, Call waiting, Do

not disturb, DTMF, Echo cancellation,

Fax-tone detection pass-through,

Silence suppression, VAD

Phone Connectors:

2 x RJ-11 (POTS-FXS)

General
Power input

12 Vdc 1.25A plug-pack included

for the regions as listed

Mains:

100~240Vac - 50/60Hz - 0.6 A

Power consumption:

CATV receiver:

2.7 W

Fast Ethernet node:

3.4 W

Operating temperature:

-10 °C to 40 °C

Storage temperature:

-20 °C to 70 °C

Dimensions: (HxWxD)

140 x 220 x 30 mm

Ship size: (HxWxD)

215 x 273 x 99 mm

Weight

0.5 kg

Ship weight

4100, 4100V

0.8 kg

4100T, 4100VT

1 kg

Light Link

®

Direct 4100 Specifications
