Blue|328
Digital Audio Mixer
Specifications
GENERAL
AUDIO INPUTS:
4 input slots, 32 channels max
Digital:
AES3id, SDI
Analog:
Balanced Line Level
Mic Level
AUDIO OUTPUTS:
AES: 4
AES3id
Analog:
8 Balanced Analog, 1 Stereo Headphone
Optional:
1 Optional output slot (8 channels), can
be configured as Analog or Digital,
switchable between Program, Meter, or
Monitor outputs
EQUALIZER:
3-band Parametric w/notches
DYNAMICS:
Compressor/Limiter/Expander
AUDIO DELAY:
16 Video Frames per input maximum @
48kHz
TONE GENERATOR:
Internal 1kHz
PHASE REVERSAL:
180° switchable on left input pair
SAMPLE RATE:
48kHz/96kHz/192kHz
TIMING INPUT:
Video Sync:
NTSC(29.97fps), PAL(25fps), HDTV
(60Hz, 59.94Hz, 48Hz, 48/1.001Hz,
25fps, 24fps, 24/1.001Hz
Audio Sync:
AES3id
SETUP REGISTERS:
200 User Programmable
METERS:
Standard:
Internal, Proprietary
Optional:
Mx Metering System
Customer-supplied w/Optional Output
Module
POWER
Voltage Requirements:
100-240VAC
Frequency: 50-60
Hz
Power Consumption:
60 Watts
Operating Temperature:
10-40˚ Centigrade
CONNECTIONS
INPUTS:
Analog Line Level:
15-pin D-Sub Breakout
Analog Microphone:
XLR
AES Digital:
BNC
SDI Digital:
BNC
Sync:
BNC
OUTPUTS:
Analog:
25-pin D-Sub Breakout
AES Digital:
BNC
Headphone:
Stereo Phone Jack (TRS), 1/4"
Meter:
RJ-11
INTERFACE:
Ethernet (TCP/IP):
RJ-45 (PC Status Application Support)
GPI (4 optional inputs):
9-pin D-Sub (PGM select, Record select,
Recall Next Register, Recall Register 1)
PERFORMANCE
ACCURACY:
64-bit Floating Point Internal
24-bit I/O
DIGITAL AES OUTPUTS:
Number:
4 AES pairs (8 channels)
Format:
AES3id (24 bit)
Impedance:
75
Ω unbalanced
Sample Rate:
48kHz/96kHz/192kHz
ANALOG OUTPUTS:
Number:
8 Line Level
Dynamic Range:
> 102 dB (>105 dB Optional Out)
Coupling:
DC Active - Balanced
Source Impedance:
< 30
Ω
Frequency Range:
20 - 20kHz (± .1dB)
Level:
+22dBu into 600
Ω
DIGITAL AES INPUTS:
Number:
4 AES pairs (8 channels)
Format:
AES3id (24 bit)
Impedance:
75
Ω unbalanced
Sample Rate:
48 kHz/96kHz/192kHz (32kHz - 192kHz
with optional sample rate converter)
ANALOG INPUTS
Number:
4 Line Level
2 Microphone (optional)
Dynamic Range:
>100dB
Impedance:
>10k
Ω bridging or terminating
Frequency Range:
20 - 20kHz (± .1dB)
Nominal Gain Range:
-22dBu -+10dBu
MICROPPHONE INPUTS
Number:
2
Dynamic Range:
>100dB
Impedance: >10k
Ω bridging or terminating
Frequency Range:
20 - 20kHz (± .1dB)
Microphone Gain Range:
-62dBu - -15dBu
Phantom Power:
48V, switchable
SD/HD SDI:
De-embedder:
1 SDI input, 8 channels audio selectable
Number:
from audio groups 1 – 4 1 SDI Output,
active loop-through
Embedder:
1 SDI reference input 1 SDI output,
Number:
8 channels audio selectable audio
groups 1 – 4
Format:
SD or HD, auto-detection
Impedance: 75Ω
unbalanced
HD Serial Digital:
1.485 Gb/s, SMPTE 274M, 292M, 296M
SD Serial Digital:
270 Mb/s, SMPTE 259M-C
Return Loss:
>15 dB
Mixer Sample Rate:
(SRC bypass) 48kHz Only (SDI Locked)
(SRC enabled) 48kHz/96kHz/192kHz
PHYSICAL DIMENSIONS
Width: 11.1" (28.19cm)
Height(Front): 1.4" (3.56cm)
Depth: 11.4" (28.96cm)
Height(Rear): 7.14" (18.14cm)
Weight: (fully optioned, including power supply): 11 pounds (5kg)
