Toner Cable HD7084P High Definition VHF-UHF Antenna User Manual
Hd7084p, Platinum series high definition vhf/uhf antenna, Polar patterns
Specifications Subject To Change Without Notice
Rev 06-12
©Toner Cable Equipment, Inc.
HD7084P
Platinum Series High Definition
VHF/UHF Antenna
969 Horsham Road
l
Horsham, Pennsylvania 19044 USA
l
Phone: 215-675-2053 Fax: 215-675-7543
l
Active Elements
68
UHF Elements
40
VHF Elements
28
Boom Length
131"
Turning Radius
81"
Maximum Width
110"
Vertical Height
25.5"
Element Diameter
3/8"
Shpg. Weight
13.5 lbs
Carton Dimensions
6.25" x 6.25" x 104.25"
Output Impedance
75 ohm
Recommended Preamp
AP Series
Channel
Ch.2
Ch.4
Ch.6
Ch.7
Ch.9
Ch.11
Ch.13
Ch.14
Ch.32
Ch.50
Ch,69
dB gain over
6.2
7.2
7.6
10.9
12
10.9
10.8
14.6
12.1
11.8
10.2
reference dipole
beamwidth at half of
69°
68°
68°
31°
33°
46°
34°
42°
41°
36°
22°
power points
front-to-back
20 dB
greater
greater
19 dB
17 dB
15 dB
17 dB
11 dB
20 dB
20 dB
12 dB
ratio
than than
20 dB
20 dB
POLAR PATTERNS
