Multiplexer Specifications
Program Filtering and Grooming Each encoder output can be disabled or output to any or all
output channels
Multiplexer All programs directed to each output are multiplexed into a
available on EH244-IPQ late summer 2013 correct multi-program transport stream
ASI Output An optional ASI output board may be ordered that mirrors the
available on EH244-IPQ late summer 2013 4 QAM channel output transport streams
PSIP Table Handling
PSIP Table Rewriting Supported
MGT/VCT Table Generation Supported
SCTE18 EAS Generation Supported
Output
1000Base-T Ethernet 1 x RJ45 Gigabit Ethernet (GbE)
(GbE) Connector Format
Data Throughput
214 Mbps
Standard IEEE 802.3 10/100/1000 Base-T Ethernet
Packet Frame-rate RTP within UDP
Source Address Assignment Single IPv4 address & port; user-selectable
Destination Address Assignment Per-channel IPv4 address & port configurable; supports
multicast destinations only
ASI Connector 2 x BNC
Format DVB-ASI
Data Throughput 214 Mbps
Standard ETSI EN 50083-9
General
Temperature Rating 0-50°C ambient
Form Factor 2RU 19" rack enclosure
Dimensions 14.25"D x 3.5"H x 19" W
Weight 9.5 lbs
Power Requirements 90-260VAC 65W maximum
Specifications
EH244-IP
Encoder Host
