RX8320
ATSC Broadcast Receiver
Video and Audio Formats
MPEG-2 SD Video Decode
MPEG-2 MP@ML video decoding
15 Mbps maximum video rate
Input video format: 480i @ 29.97 fps
MPEG-2 HD with Down-conversion
MPEG-2 MP@HL video decoding
Input video format: 1080i @ 29.97 fps and
720p @ 59.94 fps
80 Mbps maximum video input rate
High definition video down-converted and pre-
sented as SD only
SD video format: 480i @ 29.97 fps
Video Processing
AFD and bar data picture aspect ratio conver-
sion and signaling per SMPTE 2016
CEA-608 closed captions and XDS on line 21
Nielsen AMOL in VBI
Ancillary and Metadata Processing
SCTE 35 DPI cue message pass-through on
transport stream output
SCTE 127 (including Nielsen AMOL-48/-96, TV
Guide TVG2X) pass-through and translation to
VBI
Closed captions and XDS extracted from CEA-
708 DTVCC transport channel
PSIP pass-through on transport stream output
Translation of PSIP content advisory to XDS
program rating (V-Chip)
Audio Decoding
Two stereo pairs audio decoding
Dolby Digital® 2.0 decoding
Dolby Digital 5.1 down-mix to 2.0
Video and Audio Options
MPEG-4 AVC HD with Down-conversion
MPEG-4 AVC MP@L4 and HP@L4 decoding
20 Mbps maximum video input rate
Video format: 1080i @ 29.97 fps and 720p @
59.94 fps
High definition video down-converted and pre-
sented as SD only
SD video format: 480i @ 29.97 fps
MPEG-4 AVC SD
MPEG-4 AVC MP@L3 and HP@L3 decoding
12 Mbps maximum video input rate
Video format: 480i @ 29.97 fps
Input Interfaces
Transport Stream Input
ASI connector: 1x BNC 75 Ohm
Max input rate: 160 Mbps
Packet length: 188/204 bytes
8-VSB RF Input
Connector: 1x F-Type (F), 75 Ohm
Modulation: ATSC A/53 8-VSB
Frequency range: 54 MHz to 863 MHz
Input level: -80 dBm to -5 dBm
Bit-rate: 19.39 Mbps
Outputs
Transport Stream Output
ASI connector: 2x BNC 75 ohms
Composite Video Output
Connector: 2x BNC 75 ohms
Format: NTSC
Audio Output
Analog balanced audio output
2x 9-pin D-type with breakout cable to XLR
connectors
Output Options
Transport Stream Output
Transport stream encapsulation into IP
MPTS/UDP/IP
2x Gigabit Ethernet outputs (RJ45)
100/1000BaseT auto-sensing
Hardware always fitted, enabled with feature
key
Features
Program selection for ATSC, DVB and MPEG-
only streams
Input transport stream rate up to 160 Mbps
Alarm relay
Stream Processing
Single Service filtering
Filter multiple services to one outgoing service
y
Remap PIDs for the filtered service
Output: CBR on ASI and IP
y SPTS
Multi-service filtering
Filter N incoming services to M outgoing ser-
vices
y
Number of services: 24 max.
Remap PIDs on a single service
Output: CBR on ASI and IP
y MPTS
Stream splitting - up to 8 services as IP SPTS
Control Options
Front panel keypad and LCD
Ethernet
Dual RJ45 10/100BaseT control interface
SNMP traps and alarms
Web browser interface
Physical and Power
Dimensions (W x D x H)
440 x 400 x 44mm
(17.3 x 15.75 x 1.73“ approx.)
Input Voltage
110 VAC / 240 VAC
Power Consumption
45 Watt max. (depending on options fitted)
Cooling
Integrated fans
Environmental Conditions
Operating Temperature
0°C to 50°C (32° to 122°F)
Storage Temperature
-20°C to 70°C (4° to 140°F)
Relative Humidity
5% to 95% (Non-condensing)
Compliance
CE marked in accordance with EU Low
Voltage and EMC Directives
EMC Compliance
EN55022, EN61000-3-210, EN61000-3-310,
EN55024, CISPR22, FCC CFR47 Part 15B
Class A
Safety Compliance
EN60950-1, IEC60950-1, UL60950-1
SPECIFICATIONS
