Toner Cable CynerG2 Dual Program Digital SD or HD Character Generator - Manual (Page 2)

©Toner Cable Equipment, Inc. Specifications Subject To Change Without Notice.
Telephone: Nationwide: Fax: E-mail: Internet:
CynerG2 Br
oadcast Gr
a
phics System
215-675-2053 800-523-5947 215-675-7543 [email protected] http://www.tonercable.com
CynerG 2 HD
2-channel HD-SDI/SD-SDI broadcast
graphics system. SMPTE 292M/259M
compliant I/O. 1080i and 720p HD with
two full featured CG channels, can be
used with or without a video switcher.
CynerG 2 HD Ready
2-channel SD-SDI broadcast graphics
system upgradeable to CYNERG2 HD
via firmware. Contains same hardware as
HD system.
CynerG 2 SD-SDI
2-channel SD-SDI and analog broadcast
graphics system. SMPTE 259M and
170M compliant I/O, use with or without a
video switcher. Supports SD 16:9 and 4:3
aspect ratios. Not upgradeable to HD.
CynerG 2 Analog
2-channel analog broadcast graphics
system upgradeable to full CYNERG2
SD-SDI via firmware. Contains the same
hardware as CYNERG2 SD-SDI. Not
upgradeable to HD.
CynerG 2 HD and HD Ready
Video I/O Standards Supported
SD-SDI
SMPTE 259M
(both 4:3 and 16:9 supported)
HD-SDI (option for HD Ready)
SMPTE 292M
1920x1080i (60/59.94/50)
1280x720p (60/59.94/50)
Input
(2) SD-SDI, Passes VBI
(2) HD-SDI, Passes HANC and VANC
(option for HD Ready)
Output
(2) SD-SDI key and fill
(2) HD-SDI key and fill (option for HD
Ready)
(2) DVI-D Display Monitor
System Genlock
SD-SDI, BB
HD-SDI, BB, Tri-level Sync
Internal, Input video
CynerG 2 SD-SDI and Analog
Video I/O Standards Supported
Analog
SMPTE 170M
NTSC 720x486
PAL 720x576
SD-SDI (option for Analog)
SMPTE 259M
(both 4:3 and 16:9 supported)
Input
(2) Composite, YPbPr, Y/C, Passes VBI
(2) SD-SDI, Passes VBI (option for
Analog)
Output
(2) Composite, YPbPr, Y/C fill
(2) Composite key
(2) SD-SDI key and fill (option for Analog)
VGA and DVI-D Display Monitor
System Genlock
Reference Input (BB or CVBS)
Internal, Input video
CynerG 2 All Systems
Minimum System Specifications
CPU
Intel Core 2 Duo 3.33 GHz
OS
Windows XP Professional
RAM
2GB
Hard Drive
320GB SATA HDD (7200RPM)
Optical Drive
22x DVD-RW
All in 1 Internal Card Reader
Ports
1 Ethernet 1000BaseT (RJ-45)
1 RS-232 (DB9)
6 USB 2.0
Power Specifications
Power Supply : 500W
110/220 Volt 60/50 Hz (Auto-sense)
Dual redundant hot swappable supplies
(Option for all configurations)
Physical Dimensions
4RU rack mount chassis
Height : 7 inches (17.78cm)
Width : 19 inches (48.26cm)
Depth : 20 in (50.80cm)
Weight : 36½lb (16.55kg)
Dual Channel Playback
CynerG2 gives the user total control of playback for
both channels simultaneously with the Multi-Playback
window. Dual channel operation is combined into a
single elegant interface.
