DCM4-HDz
Digital Settop Converter
Specifications
Categories Functions Specification
CPU CPU EMMMA3 SL/P
Memory Flash Memory 4 MB
SDRAM 128 MB
Tuner & Modulation Input 54 - 864 MHz
(In-Band Tuner) RF Input Connector F-Connector, Female
RF-Loop Through F-Connector, Female (in standby mode)
RF3/4 Modulation NTSC Out w/Channel 3/4
RF Input Level -12 ~ +15 dBmV @ 256 QAM
-15 ~ +15 dBmV @ 64 QAM
Demodulation 64 QAM / 256 QAM (Annex 6)
Channel Spacing 6 MHz
Input Symbol Rate QAM, 5.057 / 5.361 Msymbol/sec
Video Decoder Transport Stream MPEG2 ISO / IEC 13818-1
Profile Level MPEG2 MP @ ML (SD)
MPEG2 MP @ HL (HD)
MPEG4 AVC, H.264 (HD)
Video Data Rate Max 30 Mbps
Video Format 4:3 / 16:9, Letter Box / Stretch / Crop
Video Resolution 480i, 480p, 720p, 1080i
Audio Decoder Mode Dolby AC3 (5.1 ch down-mix stereo)
MPEG Audio Layer 1, 2
Dual Mono, Stereo, Joint Stereo
Sampling Frequency 32K / 44.1K / 48K
Back-Panel A/V Output Composite & Stereo LR (phone to 3 RCA Jack) x1
HDMI (w/HDCP) x1
USB Port USB 2.0 (S/W Upgrade Use Only) x1
External IR Stereo Type Connector
CH 3/4 NTSC Out, CH 3/4 Selection Switch
Power Power Adaptor AC 120 ± DC 5.5 V 2 A
SW EPG PSIP and DVB-C Based
Subtitle DVS026 (Digicipher)
Caption DTV-CC (EIA-708-B, Comply with FCC mandate)
Analog CC (EIA-608A)
Channel Autoscan, Channel Edit, Information, Favorite,
Signal
Rating Parental Control (ATSC, DVB-C)
Others Volume, Mute, Audio Language
Software Update OTC Over The Cable
USB 2.0
Contents Protection Smart Card SIM Card (Rear, Push Type)
Copy Protection Macrovision, HDCP
Included in Carton Remote Control Universal RCU
A/V Cable Phone to 3RCA Cable (CVBS, L/R)
RF Cable 1.2m
User’s Manual User’s Manual
Physical Size / Weight 6.75” x 5” x 1.5” , 14 oz
