Pico Macom PMN-1 Mini Indoor Optical Node
215-675-2053
800-523-5947
215-675-7543
http://www.tonercable.com
PMN-1 Specifications
Forward Receiver
Symbol Parameter
Conditions
Min. Typ. Max. Unit
λ
Optical Wavelength
-
1290
-
1600
nm
VOpt. In. Monitor Voltage
λ=1310 -
1
-
V/mW
Pin
Optical Input Power
Continuous
-6
1
3
dBm
f Frequency
Range
-
54
-
1000
MHz
FL
Freq. Response Flatness
f=53~1000MHz
-
±0.5
-
dB
S22
Output Return Loss
f=53~1000MHz
15
16
-
dB
Vo
Output Level
-
-
25
-
dBmV
Optical Return Loss
-
45
-
-
dB
CTB
Composite Triple Beat
99chs flat,
-
-
-61
dB
CSO
Composite Second Order
fm=859.25MHz
-
-
-60
dB
Return Transmitter
Symbol Parameter
Conditions
Min. Typ. Max. Unit
λ
Optical Wavelength
-
-
1310
-
nm
WOut
Optical Output Power
Continuous
0.5
1
3
dBm
VOpt. In. Monitor Voltage
λ=1310 -
1
-
V/mW
Vrin.
RF Input Level
-
-
15
-
dBmV
f
Frequency Range (option)
-
5
-
42
MHz
FL
Freq. Response Flatness
f=5~42MHz
-
±0.5
-
dB
S11
Input Return Loss
f=5~42MHz
15
16
-
dB
Optical Output Return Loss
-
-
45
-
dB
General
Symbol Parameter
Conditions
Min. Typ. Max. Unit
Itot
Total Current Consumption
V+=12V
-
350
-
mA
Dimensions: 7.5" L x 4.2" W x 3.3" H
Weight: 0.75 lbs
