VM-3 Specifications
(VM-3) Text Generator & Video
Controller
• Color text with multiple font
selections • Schedule by date
range, day and time • Run
messages on as many
channels as desired (optional
equipment required)
• Requires no PC • Extremely
user friendly • 1/2RU
• 120VAC, 60Hz (220VAC
model available) • IEC 320
plug • UL listed
Applications
• Hotels (meetings, internal
promotions) • Conference
Centers • Cable Companies
• Banks • Retail • Brokerages
• Schools and Institutional
• Railroad stations
• Commercial environments
• Any application that needs
quick and easy information
delivery • Display recreational
activities • Meeting schedules
• Menu specials • Stock alerts
• Interest rates • Weather &
sports updates
Video Attributes
• 640 x 480 resolution • 16
basic colors plus fine adjust
• 1 small sized system font
(avg. 50 characters across the
page) • 3 medium sized fonts
(avg. 30-45 characters across
the page) • 1 large sized font
(avg. 18-20 characters across
the page)
Connections
• One video jack (in) and 2
video jacks (out): one for edit
monitor and one for TV system
or floor display • 2X MIDI (din
5): one in and one out • two
RS 232 (9 pin) jacks for
keypad operation, external
DVD player, modem or
IP/LAN Connection
• Front panel 5-pin connector
for AT101 keyboard
Software
Up to 250 full screen
messages or crawl lines
• Color by line • Copy/paste by
message• Copy/paste
message attributes • Clear
function by selected
paragraph • Insert function at
cursor position • Date,
day/time scheduling by
message • Multi- channel
operation via daisy chained
network units • Message
routing (by daisy chained
network units) • Advanced edit
navigation features • Delete by
character, paragraph and
message • Font size and style
by line and paragraph • Image
and video file linking by page
• Flexible message length
• Remote operation via Modem
or IP/LAN Interface • Help
function on all menus
VM-3 includes a full AT101
Keyboard...................
Note: This system is designed as a
video bulletin board with built-in
backgrounds of various colors. It
will also genlock text messages
over any external video source.
VM-3 Local Network Unit
• Allows display of separate
messages to be shown
simultaneously in separate
areas of a location, i.e.,
cafeteria, lobby, lounge, etc.
• Each Network Unit is
addressable with its own ID
• Messages can be shared
between networked units
automatically or manually
The High Impact Video Package
• Links digital CD images and
MPEG video with your text
messages for maximum
impact (like a Power Point
presentation) integrates VM- 3
Text and Video Generator &
Controller with a DVD player.
This allows the user to play
hundreds of high-resolution
images and/or MPEG video
• The VM-3 plays both images
and video clips while
overlaying text
The Modem System
• Consists of two VM-3's with
modems: one sender, one
receiver • Can control a VM-3
from remote location
• Designed as a plug and play
device with minimum setup
• Can be operated as a stand
alone or multi-media system
• Optional VMConsole
allows the storage of thousands
of messages on a PC
(Windows®) for future use.
The IP Addressing System
Using an IP to serial port
converter the VM-3 can be
installed on a LAN and
controlled via your PC .Users
can send data using the
VMConsole software which
delivers it to the VM-3. The VM-
3 converts the data stream into
video characters then
superimposes them over
programming from your cable
box, satellite receiver, VCR or
DVD Player.
