background image

Specifications Subject To Change Without Notice

Rev 04-12

©Toner Cable Equipment, Inc.

969 Horsham Road

l

Horsham, Pennsylvania 19044 USA

l

Phone: 215-675-2053 Fax: 215-675-7543

l

[email protected]

AQP

ATSC/QAM Processor 1x 8VSB/QAM ► 1x QAM

Specifications

Connector:

“F” Female

Standards

8VSB/16 VSB:

ATSC Digital Television A/53E

QAM:

ITU-T J.83 - Annex A & B
(16, 32, 64,128, and 256 QAM)

8VSB/16VSB Modes

Tuning Range:

VHF (NTSC Ch. 2-13), UHF (NTSC Ch. 14-69)

Data Rate:

19.392 Mbps

Bandwidth:

6 MHz

8VSB Power Level:

-28 to 20 dBmV

16VSB Power Level:

-25 to 20 dBmV

QAM Mode

Tuning Range:

CATV (NTSC Ch. T7-T13; 2-135)

Data Rate:

38.8 Mbps (QAM 256); 26.97 Mbps
(QAM 64) - Auto Detect

Bandwidth:

6 MHz

Power Level:

-20 to +20 dBmV

Impedance:

75 Ω

Indicators

8VSB/QAM:

Lock Status (Green LED)

Local Monitoring:

Front-panel 16-character, 2-line LCD screen

Local Control:

Front-panel Navigational Key-pad
Sub-band input on/off switch

Remote Monitoring/Control:

Not Available

INPUT

OUTPUT

ALARMS / MONITORING / CONTROL

Dimensions (W x D x H):

19 x 18.125 x 1.75 inches (483 x 460 x 44 mm)

Power:

105 to 135 VAC; 60 Hz
(Fuse:1 A, 250 VDC, SloBlo)

Power Dissipation:

23 W

Weight :

7 lbs (3.2 kg)

Operating Temperature:

32 to 122°F (0 to 50°C)

Storage Temperature:

-13 to 158°F (-25 to 70°C)

Operating Humidity:

0 to 95% RH @ 35°C max, non-condensation

Storage Humidity:

0 to 95% RH @ 35°C max, non-condensation

GENERAL

Connector:

“F” Female

QAM Modulation Modes:

16, 32, 64, 128, & 256

DVB Symbol Rate:

Variable; 1 to 7 MSymbols/sec (mbaud)

Frequency Range:

54 to 864 MHz

QAM Tuning

NTSC:

Per channel’s number from 2 to 135

PAL:

Per channel’s center-frequency
(12.5 kHz increments)

RF Level:

+55 dBmV (115 dB

μV)

RF Level LCD Screen Error:

±2 dB

RF Level Adjustment Range:

45 to 55 dBmV

Frequency Tolerance:

±0.5 kHz @ 77°F (25°C)

Frequency Stability

±5 kHz over 32 to 122°F (0 to 50°C)

Amplitude Flatness:

±0.25 dB (over 6 MHz channel)

Phase Noise:

-98 dBc (@ 10 kHz)

Spurious:

-60 dBc

Broadband Noise:

-75 dBc

(@ +55 dBmV output level, 4MHz bandwidth)

Impedance:

75

Ω

Return Loss:

12 dB

Spectral Inversion:

Auto Recognition

Carrier Suppression:

55 dB

SNR:

Greater than 40 dB

MER:

Greater than 40 dB

I/Q Phase Error:

Less than 1 degree

I/Q Amplitude Imbalance:

Less than 1%
